Chapter 12 Description of Parameter SettingsME300
12.1-00-11
Example:
If user-defined unit is inWG, user-defined decimal place is the third decimal point, according to
the information above, the corresponding unit to inWG is 01Axh (x is the set decimal point), the
corresponding unit to the third decimal place is 0003h, then inWG and the third decimal point
displayed in hexadecimal is 01A3h, converted to decimal is 01A3h = 419. Thus set Pr.00-25 =
419 to complete the setting.
Maximum User-Defined Value
Default: 0
Settings 0: Disable
0–65535 (when Pr.00-25 set to no decimal place)
0.0–6553.5 (when Pr.00-25 set to one decimal place)
0.0–655.35 (when Pr.00-25 set to two decimal places)
0.0–65.535 (when Pr.00-25 set to three decimal places)
 When Pr.00-26 is NOT set to 0, the user-defined value is enabled. After selecting the displayed
unit and number of decimal points with Pr.00-25, the setting value of Pr.00-26 corresponds to
Pr.01-00 (Maximum motor operating frequency), and then the motor operation frequency has a
linear relationship with the displayed value on the digital keypad.
Example:
When the frequency set in Pr.01-00 = 60.00 Hz, the maximum user-defined value for Pr.00-26 is
100.0%. This also means that Pr.00-25 is set at 0021h to select % as the unit.
NOTE
The drive display is controlled by the Pr.00-25 setting when Pr.00-25 is properly set and Pr.00-26
is not 0.
User-Defined Value
Default: Read only
Settings Read only
 Pr.00-27 displays the user-defined value when Pr.00-26 is not set to 0.
 The user-defined value is valid only when Pr.00-20 (frequency source) is set to the digital keypad
or to RS-485 communication.
LOCAL / REMOTE Mode
Default: 0
Settings 0: Standard HOA function
1: Switch Local / Remote, the drive stops
2: Switch Local / Remote, the drive runs as the REMOTE setting for
frequency and operation status
3: Switch Local / Remote, the drive runs as the LOCAL setting for frequency
and operation status
4: Switch Local / Remote, the drive runs as LOCAL setting when switched to
Local and runs as REMOTE setting when switched to Remote for
frequency and operation status.
