Delta VFD1A5MS43ANSAA User Manual

Chapter 11 Summary of Parameter SettingsMS300
213
01 Basic Parameters
Pr.
Explanation
Settings
Default
01-00
Maximum Operation
Frequency of Motor 1
0.00–599.00 Hz
60.00 /
50.00
01-01
Rated / Base Frequency of
Motor 1
0.00–599.00 Hz
60.00 /
50.00
01-02
Rated / Base Voltage of
Motor 1
115V / 230V models: 0.0–255.0 V
460V models: 0.0–510.0 V
575V models: 0.0–637.0 V
220.0
440.0
575.0
01-03
Mid-Point Frequency 1 of
Motor 1
0.00–599.00 Hz
3.00

01-04
Mid-Point Voltage 1 of
Motor 1
115V / 230V models: 0.0–240.0 V
460V models: 0.0–480.0 V
575V models: 0.0–600.0 V
11.0
22.0
40.0
01-05
Mid-Point Frequency 2 of
Motor 1
0.00–599.00 Hz
1.50

01-06
Mid-Point Voltage 2 of
Motor 1
115V / 230V models: 0.0–240.0 V
460V models: 0.0–480.0 V
575V models: 0.0–600.0 V
5.0
10.0
26.1
01-07
Minimum Output Frequency
of Motor 1
0.00–599.00 Hz
0.50

01-08
Minimum Output Voltage of
Motor 1
115V / 230V models: 0.0–240.0 V
460V models: 0.0–480.0 V
575V models: 0.0–600.0 V
1.0
2.0
16.7
01-09
Start-Up Frequency
0.00–599.00 Hz
0.50

01-10
Output Frequency Upper
Limit
0.00–599.00 Hz
599.00

01-11
Output Frequency Lower
Limit
0.00–599.00 Hz
0.00

01-12
Acceleration Time 1
Pr.01-45 = 0: 0.00–600.00 sec.
Pr.01-45 = 1: 0.0–6000.0 sec.
10.00

01-13
Deceleration Time 1
Pr.01-45 = 0: 0.00–600.00 sec.
Pr.01-45 = 1: 0.0–6000.0 sec.
10.00

01-14
Acceleration Time 2
Pr.01-45 = 0: 0.00–600.00 sec.
Pr.01-45 = 1: 0.0–6000.0 sec.
10.00

01-15
Deceleration Time 2
Pr.01-45 = 0: 0.00–600.00 sec.
Pr.01-45 = 1: 0.0–6000.0 sec.
10.00

01-16
Acceleration Time 3
Pr.01-45 = 0: 0.00–600.00 sec.
Pr.01-45 = 1: 0.0–6000.0 sec.
10.00
