Chapter 16 PLC Function ApplicationsMS300
684
16-5 Various PLC Device Functions
Item
Specifications
Notes
Algorithmic control
method
The program is stored internally, alternating back-and-
forth scanning method.
The input point renews when the
scanning starts, and the output point
renews when the scanning ends.
Input / output
control method
When the scan starts again after ending (after execution
to the END command), the input/output is immediately
refreshed.
Algorithmic
processing speed
Basic commands (several μs);
Application command
(1 to several tens of μs)
Programming
language
Command + ladder diagram
Program capacity
2000 steps
Input / output
contacts
Digital input (X): 7; digital output (Y): 3
Analog input: 2; analog output: 1
Table 16-7
Type
Device
Item
Range
Function
Relay bit form
X
External input relay
X0–X17, 16 points, octal
number
Total
32
points
Corresponds to external input
point
Y
External output relay
Y0–Y17, 16 points, octal
number
Corresponds to external output
point
M
Auxiliary
Relay
General Use
M0–M799, 800 points
Total
1080
points
Contact can switch ON/OFF
within the program
Special
purpose
M1000–M1279, 280
points
T
Timer
100 ms timer
T0–T79, 80 points
Total
80
points
Timers referred to by the TMR
command; T contact with the
same number switches ON
when the time is reached.
C
Counter
16-bit counter,
general use
C0–C39, 40 points
Total
40
points
Counter referred to by the CNT
command; C contact with the
same number switches ON
when the count is reached.
Register word data
T
Current timer value
T0–T79, 80 points
The contact switches ON when
the time is reached.
C
Current counter value
C0–C39, 16-bit counter 40 points
The counter contact switches
ON when the count is reached.
D
Data
Register
Used to
maintain
power OFF
D0–D9, 10 points
Total
420
points
Used as data storage memory
area
General use
D10–D199, 190 points
Special
purpose
D1000–D1219, 220
points
Constant
K
Decimal
Single-byte
Setting Range: K-32,768–K32,767
Double-byte
Setting Range: K-2,147,483,648–K2,147,483,647
H
Hexadecimal
Single-byte
Setting Range: H0000–HFFFF
Double-byte
Setting Range: H00000000–HFFFFFFFF
Serial communication port
(program write / read)
RS-485 / USB / keypad port
Analog input/output
Built-in two analog inputs and one analog output
High-speed counting
Built-in a (MI7) 32-bit high-speed counter
Function expansion module
Optional
Accessories
--
Communication Expansion
Module
Optional
Accessories
CMM-COP02 (CANopen)
Table 16-8

Delta VFD1A5MS43ANSAA Specifications

General

Model	VFD1A5MS43ANSAA
Cooling Method	Fan Cooling
Enclosure Rating	IP20
Manufacturer	Delta
Control Method	V/F control, Sensorless vector control
Overload Capacity	150% for 60 seconds
Protection Features	Over-voltage, Over-current, Overheat, Under-voltage, Ground Fault, Short Circuit
Communication Interface	RS-485
Operating Temperature	-10°C to 50°C
Input Voltage	3-phase 380-480V AC
Storage Temperature	-20°C ~ +60°C (-4°F ~ +140°F)
