Chapter 11 Summary of Parameter SettingsMS300
218
02 Digital Input / Output Parameters
Pr.
Explanation
Settings
Default
02-00
Two-Wire / Three-Wire
Operation Control
0: No function
1: Two-wire mode 1, power on for operation control
(M1: FWD / STOP, M2: REV / STOP)
2: Two-wire mode 2, power on for operation control
(M1: RUN / STOP, M2: REV / FWD)
3: Three-wire, power on for operation control
(M1: RUN, M2: REV / FWD, M3: STOP)
4: Two-wire mode 1, Quick Start
(M1: FWD / STOP, M2: REV / STOP)
5: Two-wire mode 2, Quick Start
(M1: RUN / STOP, M2: REV / FWD)
6: Three-wire, Quick Start
(M1: RUN, M2: REV / FWD, M3: STOP)
IMPORTANT
1. In the fast start-up function, terminal output keeps in
the ready status, and the drive responses to the
command immediately.
2. When using Quick Start function, the output
terminals UVW are with driving voltages in order to
output and respond immediately if a Start command
is given. Do not touch the terminals or modify the
motor wiring to prevent electric shocks.
1
02-01
Multi-Function Input
Command 1 (MI1)
0: No function
1: Multi-step speed command 1
2: Multi-step speed command 2
3: Multi-step speed command 3
4: Multi-step speed command 4
5: Reset
6: JOG operation
[by external control or KPC-CC01 (optional)]
7: Acceleration / deceleration speed inhibit
8: 1
st
and 2
nd
acceleration / deceleration time selection
9: 3
rd
and 4
th
acceleration / deceleration time selection
10: External Fault (EF) Input (Pr.07-20)
11: Base Block (B.B.) input from external
12: Output stop
13: Cancel the setting of auto-acceleration / auto-
deceleration time
15: Rotating speed command from AVI
0
02-02
Multi-Function Input
Command 2 (MI2)
0
02-03
Multi-Function Input
Command 3 (MI3)
1
02-04
Multi-Function Input
Command 4 (MI4)
2
02-05
Multi-Function Input
Command 5 (MI5)
3
02-06
Multi-Function Input
Command 6 (MI6)
4
02-07
Multi-Function Input
Command 7 (MI7)
0
