03 Analog Input / Output Parameters
Pr.
Explanation
Settings
Default

03-00
Analog Input Selection
(AVI)
0: No function
1: Frequency command
2: Torque command (torque limit under speed mode)
3: Torque compensation command
4: PID target value
5: PID feedback signal
6: Thermistor (PTC) input value
7: Positive torque limit
8: Negative torque limit
9: Regenerative torque limit
10: Positive / negative torque limit
11: PT100 thermistor input value
12: Auxiliary frequency input
13: PID compensation value
1

03-01
Analog Input Selection
(ACI)
0

03-03
Analog Input Bias (AVI)
-100.0–100.0%
0

03-04
Analog Input Bias (ACI)
-100.0–100.0%
0

03-07
Positive / Negative Bias
Mode (AVI)
0: No bias
1: Lower than or equal to bias
2: Greater than or equal to bias
3: The absolute value of the bias voltage while serving as
the center
4: Bias serves as the center
0

03-08
Positive / Negative Bias
Mode (ACI)

03-10
Reverse Setting when
Analog Signal Input is
Negative Frequency
0: Negative frequency input is not allowed.
The digital keypad or external terminal controls the
forward and reverse direction.
1: Negative frequency input is allowed.
Positive frequency = run in a forward direction;
negative frequency = run in a reverse direction.
The digital keypad or external terminal control cannot
change the running direction.
0

03-11
Analog Input Gain (AVI)
-500.0–500.0%
100.0

03-12
Analog Input Gain (ACI)
-500.0–500.0%
100.0

03-15
Analog Input Filter Time
(AVI)
0.00–20.00 sec.
0.01

03-16
Analog Input Filter Time
(ACI)
0.00–20.00 sec.
0.01

03-18
Analog Input Addition
Function
0: Disable (AVI, ACI)
1: Enable (excludes analog extension card)
0
