Delta VFD1A5MS43ANSAA User Manual

Chapter 11 Summary of Parameter SettingsMS300
243
08 High-function PID Parameters
Pr.
Explanation
Settings
Default

08-00
Terminal Selection of PID
Feedback
0: No function
1: Negative PID feedback: by analog input
(Pr.03-00, Pr.03-01)
2: Negative PID feedback: by single-phase input (MI7),
without direction (Pr.10-16 = 5)
4: Positive PID feedback: by analog input (Pr.03-00,
Pr.03-01)
5: Positive PID feedback: by single-phase input (MI7),
without direction (Pr.10-16 = 5)
7: Negative PID feedback: by communication protocols
8: Positive PID feedback: by communication protocols
0

08-01
Proportional Gain (P)
0.0–1000.0 (When Pr.08-23 bit 1 = 0)
0.00–100.00 (When Pr.08-23 bit 1 = 1)
1.00

08-02
Integral Time (I)
0.00–100.00 sec.
1.00

08-03
Differential Time (D)
0.00–1.00 sec.
0.00

08-04
Upper Limit of Integral
Control
0.0–100.0%
100.0

08-05
PID Output Command
Limit (Positive Limit)
0.0–110.0%
100.0

08-06
PID Feedback Value by
Communication Protocol
-200.00–200.00%
0.00

08-07
PID Delay Time
0.0–2.5 sec.
0.0

08-08
Feedback Signal
Detection Time
0.0–3600.0 sec.
0.0

08-09
Feedback Signal Fault
Treatment
0: Warn and continue operation
1: Fault and ramp to stop
2: Fault and coast to stop
3: Warn and operate at last frequency
0

08-10
Sleep Level
0.00–599.00 Hz / 0.00–200.00%
0.00

08-11
Wake-Up Level
0.00–599.00 Hz / 0.00–200.00%
0.00

08-12
Sleep Delay Time
0.0–6000.0 sec.
0.0

08-13
PID Feedback Signal
Error Deviation Level
1.0–50.0%
10.0

08-14
PID Feedback Signal
Error Deviation Detection
Time
0.1–300.0 sec.
5.0

08-15
PID Feedback Signal
Filter Time
0.1–300.0 sec.
5.0
