Delta VFD1A5MS43ANSAA User Manual

Chapter 3 InstallationMS300
19
3-2 Airflow and Power Dissipation
Frame
Airflow Rate for Cooling
Power Dissipation for AC Motor Drive
Model No.
Flow Rate
(Unit: cfm)
Flow Rate
(Unit: m
3
/ hr)
Loss External
(Heat sink, unit: W)
Internal
(Unit: W)
Total
(Unit: W)
A
VFD1A6MS11ANSAA
VFD1A6MS11ENSAA
0.0
0.0
8.0
10.0
18.0
VFD2A5MS11ANSAA
VFD2A5MS11ENSAA
14.2
13.1
27.3
VFD1A6MS21ANSAA
VFD1A6MS21ENSAA
8.0
10.3
18.3
VFD2A8MS21ANSAA
VFD2A8MS21ENSAA
16.3
14.5
30.8
VFD1A6MS23ANSAA
VFD1A6MS23ENSAA
8.6
10.0
18.6
VFD2A8MS23ANSAA
VFD2A8MS23ENSAA
16.5
12.6
29.1
VFD4A8MS23ANSAA
VFD4A8MS23ENSAA
31.0
13.2
44.2
VFD1A5MS43ANSAA
VFD1A5MS43ENSAA
17.6
11.1
28.7
VFD2A7MS43ANSAA
VFD2A7MS43ENSAA
30.5
17.8
48.3
VFD1A7MS53ANSAA
23.5
12.5
36
B
VFD1A6MS21AFSAA
0.0
0.0
8.0
10.3
18.3
VFD2A8MS21AFSAA
10.0
16.99
16.3
14.5
30.8
VFD4A8MS21ANSAA
VFD4A8MS21ENSAA
0.0
0.0
29.1
20.1
49.2
VFD4A8MS21AFSAA
10.0
16.99
29.1
20.1
49.2
VFD7A5MS23ANSAA
VFD7A5MS23ENSAA
50.1
24.2
74.3
VFD1A5MS43AFSAA
17.6
11.1
28.7
VFD2A7MS43AFSAA
30.5
17.8
48.3
VFD4A2MS43ANSAA
VFD4A2MS43ENSAA
VFD4A2MS43AFSAA
45.9
21.7
67.6
VFD3A0MS53ANSAA
38.1
19
57.1
C
VFD4A8MS11ANSAA
VFD4A8MS11ENSAA
16.0
27.2
29.1
23.9
53.0
VFD7A5MS21ANSAA
VFD7A5MS21ENSAA
VFD7A5MS21AFSAA
46.5
31.0
77.5
VFD11AMS21ANSAA
VFD11AMS21ENSAA
VFD11AMS21AFSAA
70.0
35
105
VFD11AMS23ANSAA
VFD11AMS23ENSAA
76.0
30.7
106.7
VFD17AMS23ANSAA
VFD17AMS23ENSAA
108.2
40.1
148.3
