Denon AVR-2310 Service Manual

120120
AVR-2310CI/2310/890, AVC-2310
PCB HDMI ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 236810062608S IC LC89058W-E
J046890580010S
IC115 00D2623077900 IC TC74VHCU04FT J040740400080S
IC116 00D2623412905 IC TC74VHC14FT J040741400220S
IC151 963248005260D IC EPM240T100C5N J003240105010S
IC153 00D2623436907 IC TC74VHC244FT J040742440030S
IC155 231810037508S IC EN5322QI-T J080532200020S
IC202 nsp IC EN5311Q J048531100010S
IC253 246810009604S IC W9864G2GH-6 J001986460010S
IC254 245810005005D IC ADSP-21367 J080213670020S
IC255 nsp IC EN29LV160BB-70TIP J005291600050S
IC301 237810004001D IC ADAU1328 J080132800000S
IC302,303 963239005290S IC NJM2115M-TE1 J121211500020S
IC304-309 963239001880S IC AZ4580M J121458000020S
IC310 00D2631271921 IC AZ1117H-3.3 J126111733080S
IC401 236810057606S IC ADV3002XSTZ J040300200010S
IC402 nsp IC EN5335QI-T J080533500020S
IC403 231810037508S IC EN5322QI-T J080532200020S
IC501 nsp IC ADV7840 J040784000010S
IC502 247810004602S IC K4S641632N-LC60 J001464163210S
IC504 231810017504S IC TK73318WTL-G J126733180010S
IC601 nsp CERAMIC CHIP 48MHZ TXC-8W E855480000040S
IC602 nsp IC XC3S400A-4FGG320C J040340043200S
IC603 246810010604D IC IS42S32200E-6TL J001423220040S
IC604 963243005270D IC M25P40-VMN6TP J005254000010S
IC605-607 00MHC007805K0 IC TC74VHCT125AFT J040741250080S
IC608 231810071508S IC PQ012ENB1ZPH J126012010030S
IC701 236810059008S IC ADV7510 J040751000010S
IC702 00D2623436907 IC TC74VHC244FT J040742440030S
IC801 00D9630244907 IC SN74LV14APWR J040741400180S
IC802 nsp IC ABT2010 J080201000010S
IC803,804 963239004190S IC AOZ1021AI J048102100010S
IC805 nsp IC EN5311Q J048531100010S
IC851 00D2623617904 IC LP2996MX J126299600010S
IC852,853 nsp IC K4T51163QG-HCE7 J001451163070S
IC901 963243005250D IC R5F3650TNFB J020536500020S
IC903 00D2623424906 IC LTC1694 J040169400010S
IC905 00D2623437906 IC TC74VHCT244AFT J040742440040S
IC951 231810017504S IC TK73318WTL-G J126733180010S
IC952 236810058609S IC ADV7340BSTZ J045734000010S
IC955 231310009508S IC PQ033DNA1ZPH J126033010020S
IC957 231310009508S IC PQ033DNA1ZPH J126033010020S
D301 00D2760740909 D CHIP KDS184S(B3) K005018400020S
D404-436 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D440 00D2760750902 D CHIP RB521S-30 K125521300010S
D502,503 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D505,506 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D508,509 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D511,512 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D515,516 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D518,519 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D521,522 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D524,525 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D527,528 00D9630341305 D,ESD IMSA-6802-01A K067680200010S

Denon AVR-2310 Specifications

General

Equalizer	Yes
Product color	Black
Impedance	8 Ω
Frequency range	10 - 100000 Hz
Total Harmonic Distortion (THD)	0.05 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
S-Video inputs quantity	7
Component video (YPbPr/YCbCr) in	3
Dimensions (WxDxH)	431 x 377 x 171 mm
HDMI ports quantity	5
Connectivity technology	Wired
Headphone connectivity	3.5 mm
S-Video outputs quantity	2
Digital audio optical out	1

Weight and Dimensions

Weight	11200 g
