Denon AVR-2310 Service Manual

132132
AVR-2310CI/2310/890, AVC-2310
PCB DIGI POWER ASS'Y
PCB REG ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC2270,2271 963239004190S IC AOZ1021AI
J048102100010S
CAPACITORS GROUP
C2270,2271 nsp C,CERAMIC 10UF-K/16V
D011106573200S
C2272,2273 nsp C,CERAMIC 10UF-K/25V D011106574300S
C2274 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C2275,2276 nsp C,CERAMIC 10UF-K/16V D011106573200S
C2277,2278 nsp C,CERAMIC 10UF-K/25V D011106574300S
C2281 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C2285-2288 nsp C,CERAMIC 100PF-J/50V D010101167160S
OTHERS PARTS GROUP
CN2271 nsp CN,WIRE 4P
L000241040070S
CN2272 nsp CN,WIRE 4P L000101040180S
CP2270 nsp CN.WAFER 4P ANGLE L102526800400S
GND101,102 nsp TERMINAL EARTH 3790040886000S
L2270,2271 963115004260S COIL,INDUCTOR B82464Z4472M D310824644720S
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC515 00D2630801004 IC NJM7812FA
J126781200010S
IC517 00D2630801004 IC NJM7812FA J126781200010S

Denon AVR-2310 Specifications

General

Equalizer	Yes
Product color	Black
Impedance	8 Ω
Frequency range	10 - 100000 Hz
Total Harmonic Distortion (THD)	0.05 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
S-Video inputs quantity	7
Component video (YPbPr/YCbCr) in	3
Dimensions (WxDxH)	431 x 377 x 171 mm
HDMI ports quantity	5
Connectivity technology	Wired
Headphone connectivity	3.5 mm
S-Video outputs quantity	2
Digital audio optical out	1

Weight and Dimensions

Weight	11200 g
