AVR-2310CI/2310/890, AVC-2310
9. PCB INPUT ASSY
(1) Cut the wire clamp bands.
(2) Loose the Cord holder, then disconnect the connector wires and board to board.
→
TUNER PACK
→
CHASSIS BACK
Proceeding : CABINET TOP HDMI PWB ASSY
→
→
DIGI-CNT PWB ASSY
→
PCB SIRIUS ASSY
→
PCB VIDEO ASSY
→
PCB INPUT ASSY
BRACKET HDMI
→
Direction of photograph: C
cut
PCB INPUT ASSY
Board to board Cord holder : LOOSE
CP515CN303CP708
