AVR-2310CI/2310/890, AVC-2310
PARTS LIST OF P.W.B. UNIT
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model EA : Australia model
PCB MAIN ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC231 00D9600174104 IC CXA1511M-T4
J030151100010S
Q101 00D9600196302 TR KTA1268BL J5001268B0050S
Q102 00D9600196700 TR KTC3200BL J5023200B0050S
Q104 00D9600196700 TR KTC3200BL J5023200B0050S
Q104C 00D9600196700 TR KTC3200BL J5023200B0050S
Q104FL 00D9600196700 TR KTC3200BL J5023200B0050S
Q104FR 00D9600196700 TR KTC3200BL J5023200B0050S
Q104SL 00D9600196700 TR KTC3200BL J5023200B0050S
Q104SR 00D9600196700 TR KTC3200BL J5023200B0050S
Q105,106 00D9600196700 TR KTC3200BL J5023200B0050S
Q106C 00D9600196302 TR KTA1268BL J5001268B0050S
Q106FL 00D9600196302 TR KTA1268BL J5001268B0050S
Q106FR 00D9600196302 TR KTA1268BL J5001268B0050S
Q106SL 00D9600196302 TR KTA1268BL J5001268B0050S
Q106SR 00D9600196302 TR KTA1268BL J5001268B0050S
Q107C 00D9600196302 TR KTA1268BL J5001268B0050S
Q107FL 00D9600196302 TR KTA1268BL J5001268B0050S
Q107FR 00D9600196302 TR KTA1268BL J5001268B0050S
Q107SL 00D9600196302 TR KTA1268BL J5001268B0050S
Q107SR 00D9600196302 TR KTA1268BL J5001268B0050S
Q108 00D9600196700 TR KTC3200BL J5023200B0050S
Q108C 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q108FL 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q108FR 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q108SL 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q108SR 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q109,110 00D9600196700 TR KTC3200BL J5023200B0050S
Q111 00D9600196302 TR KTA1268BL J5001268B0050S
Q112 00D9630121509 TR KTC3875S J522038750210S
Q113 00D9630327808 TR KTA1281Y 2310 J5001281Y0010S
Q114 00D9600097304 TR KRC102M 2310 J6020102M0010S
Q115 00D9630121509 TR KTC3875S J522038750210S
Q128 00D9630120704 TR KRA102S J520010200210S
Q130 00D9600196302 TR KTA1268BL J5001268B0050S
Q132 00D9630245003 TR KRC106S (NF) J522010600210S
Q137 00D9630120704 TR KRA102S 890E3 J520010200210S
Q141SW 00D9630044301 TR KTC2875B(MB) 890E3 J5222875B0010S
Q142SW 00D9630044301 TR KTC2875B(MB) 890E3 J5222875B0010S
Q168-170 00D9600196302 TR KTA1268BL J5001268B0050S
Q171 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q172,173 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q174 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q175 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q176,177 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q178 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q179 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
