Denon AVR-2310 Service Manual

6
AVR-2310CI/2310/890, AVC-2310
DISASSEMBLY
• Disassemble in order of the arrow of the figure of following flow.
• In the case of the re-assembling, assemble it in order of the reverse of the following flow.
• In the case of the re-assembling, observe "attention of assembling" it.
CABINET TOP
PANEL FRONT ASSY PCB HDMI ASSY
Refer to "DISASSEMBLY 1.PANEL FRONT ASSY" Refer to "DISASSEMBL 2.PCB HDMI ASSY"
and "EXPLODED VIEW" and "EXPLODED VIEW"
PCB S/W PCB HDMI ASSY
(Ref. No. of EXPLODED VIEW : B1) (Ref. No. of EXPLODED VIEW : B23)
PCB FUNCTION ENCORDER
(Ref. No. of EXPLODED VIEW : B2)
PCB FRONT
PCB DIGI-CNT ASSY BRACKET HDMI
(Ref. No. of EXPLODED VIEW : B3)
Refer to "DISASSEMBL 4.PCB DIGI-CNT ASSY" Refer to "DISASSEMBLY 3.BRACKET HDMI"
PCB H/P and "EXPLODED VIEW" and "EXPLODED VIEW"
䇭 (Ref. No. of EXPLODED VIEW : B4) PCB DIGI-CNT ASSY BRACKET HDMI
PCB V.AUX (Ref. No. of EXPLODED VIEW : B24) (Ref. No. of EXPLODED VIEW : 42)
(Ref. No. of EXPLODED VIEW : B5) PCB DIGI_POWER ASSY
PCB FUNCTION
TUNER PAC
K
(Ref. No. of EXPLODED VIEW : B32)
(Ref. No. of EXPLODED VIEW : B6)
Refer to "DISASSEMBL 5.TUNER PACK"
PCB CNT FUNCTION and "EXPLODED VIEW"
(Ref. No. of EXPLODED VIEW : B7) TUNER PACK
PCB ENCORDER (Ref. No. of EXPLODED VIEW : 36)
(Ref. No. of EXPLODED VIEW : B8)
PCB CNT ENCORDER E2/E2A/E1C model
(Ref. No. of EXPLODED VIEW : B9)
CHASSIS BAC
K
PCB PRE OUT ASS
Y
Refer to "DISASSEMBLY 6.CHASSIS BACK" Refer to "DISASSEMBL 14.PCB PRE OUT ASSY"
and "EXPLODED VIEW" and "EXPLODED VIEW"
TRANS MAIN CHASSIS BACK PCB PRE OUT ASSY
Refer to "DISASSEMBLY 13.TRANS MAIN" (Ref. No. of EXPLODED VIEW : 34) (Ref. No. of EXPLODED VIEW : B25)
and "EXPLODED VIEW" PCB SPK
TRANS MAIN 䇭 (Ref. No. of EXPLODED VIEW : B17)
(Ref. No. of EXPLODED VIEW : 30) PCB SPK2
(Ref. No. of EXPLODED VIEW : B18)
PCB SPK_CNT
(Ref. No. of EXPLODED VIEW : B19)
PCB SIRIUS ASSY PCB SUPPLY and PCB POWER
Refer to "DISASSEMBL 7.PCB SIRIUS ASSY" Refer to "DISASSEMBLY 12.PCB SUPPLY
and "EXPLODED VIEW" and PCB POWER" and "EXPLODED VIEW"
PCB SIRIUS ASSY PCB SUPPLY (Ref. No. of EXPLODED VIEW : B13)
(Ref. No. of EXPLODED VIEW : B26) PCB POWER (Ref. No. of EXPLODED VIEW : B14)
PCB VIDEO ASSY
Refer to "DISASSEMBL 8.PCB VIDEO ASSY"
and "EXPLODED VIEW"
PCB VIDEO ASSY
(Ref. No. of EXPLODED VIEW : B23)
PCB INPUT ASSY
Refer to "DISASSEMBL 9.PCB INPUT ASSY"
and "EXPLODED VIEW"
PCB INPUT ASSY
( Ref. No. of EXPLODED VIEW : B21)
PCB CNT1 (Ref. No. of EXPLODED VIEW : B30)
PCB CPU ASSY
Refer to "DISASSEMBL 10.PCB CPU ASSY"
and "EXPLODED VIEW"
PCB CPU ASSY
( Ref. No. of EXPLODED VIEW : B27)
PCB MAIN ASSY
Refer to "DISASSEMBL 11.PCB MAIN ASSY"
and "EXPLODED VIEW"
PCB MAIN ASSY
( Ref. No. of EXPLODED VIEW : B20)
PCB 2CH ASSY
( Ref. No. of EXPLODED VIEW : B11)
PCB CNT3
( Ref. No. of EXPLODED VIEW : B28)
PCB CNT2
( Ref. No. of EXPLODED VIEW : B29)

Denon AVR-2310 Specifications

General

Equalizer	Yes
Product color	Black
Impedance	8 Ω
Frequency range	10 - 100000 Hz
Total Harmonic Distortion (THD)	0.05 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
S-Video inputs quantity	7
Component video (YPbPr/YCbCr) in	3
Dimensions (WxDxH)	431 x 377 x 171 mm
HDMI ports quantity	5
Connectivity technology	Wired
Headphone connectivity	3.5 mm
S-Video outputs quantity	2
Digital audio optical out	1

Weight and Dimensions

Weight	11200 g
