Getting Started Connections Setup Playback Information Troubleshooting
ENGLISH
n
Audio section
• Power amplier
Rated output:
Front:
100W+100W (6Ω/ohms,1kHzwith0.7%T.H.D.)
125W+125W (6Ω/ohms,1kHzwith10%T.H.D.)
Center:
100W (6Ω/ohms,1kHzwith0.7%T.H.D.)
125W (6Ω/ohms,1kHzwith10%T.H.D.)
Surround:
100W+100W (6Ω/ohms,1kHzwith0.7%T.H.D.)
125W+125W (6Ω/ohms,1kHzwith10%T.H.D.)
Output connectors: Front: 6~16Ω/ohms
Center,Surround: 6~16Ω/ohms
• Analog
Input sensitivity / Input impedance: 280mV/50kΩ/kohms
Frequency response:
20 Hz ~ 50 kHz — +1, –3 dB
S/N:
98 dB (IHF-A weighted, EXT. IN)
n
Video section
• Standard video connectors
Input / output level and impedance: 1Vp-p,75Ω/ohms
Frequency response:
5 Hz ~ 10 MHz — +1, –3 dB
• S-Video connectors
Input / output level and impedance: Y(brightness)signal—1Vp-p,75Ω/ohms
C(color)signal—0.3(PAL)/0.286(NTSC)Vp-p,75Ω/ohms
Frequency response:
5 Hz ~ 10 MHz — +1, –3 dB
• Color component video connectors
Input / output level and impedance: Y(brightness)signal—1Vp-p,75Ω/ohms
P
B / CBsignal—0.7Vp-p,75Ω/ohms
P
R / CRsignal—0.7Vp-p,75Ω/ohms
Frequency response:
5 Hz ~30 MHz — +0, –3 dB
n
Tuner section [FM] [AM]
(note:µVat75Ω/ohms,0dBf=1x10
-15
W)
Receiving Range: 87.5 MHz ~ 108.0 MHz 522 kHz ~ 1611 kHz
(87.5 MHz ~ 107.9 MHz) (520 kHz ~ 1710 kHz)
Usable Sensitivity: 1.2 µV (12.8 dBf) 18 µV
50 dB Quieting Sensitivity: MONO 2.8 µV (20.2 dBf)
STEREO 48.7 µV (45.0 dBf)
S/N (IHF-A): MONO 70 dB
STEREO 67 dB
Total harmonic Distortion (at 1 kHz): MONO 0.7%
STEREO 1.0%
Specications
n
General
Power supply: AC 230 V, 50 Hz
Power consumption:
300 W
0.8 W (Standby)
Maximum external dimensions:
440 (W) x 141 (H) x 377 (D) mm
Weight: 8.9 kg
n
Remote control unit (RC-1115)
Batteries: R03/AAA Type (two batteries)
Maximum external dimensions:
50 (W) x 211 (H) x 22 (D) mm
Weight: 110 g (including batteries)
z For purposes of improvement, specifications and design are subject to change without notice.
