Specify a name for the preset
broadcast station (Preset Name)
You can set the name to the preset broadcast station or change it.
Up to eight characters can be input.
1
Press OPTION when the input source is “HD Radio”.
The option menu screen is displayed.
2
Use ui to select “Preset Name”, then press ENTER.
The Preset Name screen is displayed.
3
Use o p to select the group of the broadcast station
you want to name.
4
Use ui to select the broadcast station you want to
name, then press ENTER.
5
Use ui to select a name label, then press ENTER.
The screen that lets you edit the Preset Name is displayed.
0
If you select “Set Defaults”, then the unit returns to displaying the
frequency.
6
Enter the characters, then press “OK”.
0
For character input, see “Using the keyboard
screen” (v
p. 188).
7
Press OPTION to return to the previous screen.
Contents Connections Playback Settings Tips Appendix
109
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X7200W

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X7200W and is the answer not in the manual?

Denon AVR-X7200W Specifications

General IconGeneral
Receiver typeSurround
Input sensitivity200 mV
Audio output channels11.2 channels
Signal-to-Noise Ratio (SNR)102 dB
Power output per channel (1KHz@6 Ohm)190 W
Power output per channel (20-20KHz@8 Ohm)210 W
HDMI in8
Audio (L/R) in7
Composite video in5
Digital audio optical in2
Ethernet LAN (RJ-45) ports1
Component video (YPbPr/YCbCr) in3
12V triggerYes
Speakers connectivity type-
AM band range522 - 1611 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM
Optical drive includedNo
DisplayLCD
Product colorBlack
Audio decodersDolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage230 V
AC input frequency50 Hz
Power consumption (standby)0.1 W
Power consumption (typical)780 W
Weight and Dimensions IconWeight and Dimensions
Depth427 mm
Width434 mm
Height196 mm
Weight17800 g
