Trigger Out 1 / Trigger Out 2
Select the conditions for activating trigger out.
For details about how to connect the TRIGGER OUT jacks, see
“TRIGGER OUT jacks” (v p. 84).
n
When setting for zone (MAIN ZONE / ZONE2 /
ZONE3)
Trigger out is activated through linkage to the power of the zone set to
“On”.
n
When setting for input source
Activates trigger out when the input source set to “On” is selected.
n
When setting for HDMI monitor
Activates trigger out when the HDMI monitor set to “On” is selected.
On:
Activate trigger on this mode.
– – –: Do not activate trigger on this mode.
Front Display
Makes settings related to the display on this unit.
o
Dimmer
Adjust the display brightness of this unit.
Bright
(Default):
Normal display brightness.
Dim: Reduced display brightness.
Dark: Very low display brightness.
Off: Turns the display off.
You can also adjust the display by pressing DIMMER on the main unit.
o
Channel Indicators
Sets whether to use the input signal display or output signal display for
the channel indication on the display.
Input:
Uses the input signal display for the channel
indication on the display.
Output
(Default):
Uses the output signal display for the
channel indication on the display.
Contents Connections Playback Settings Tips Appendix
283
Front panel Display Rear panel Remote Index
