Denon AVR-X7200W User Manual

o
Audyssey DSX
®
Provides more immersive surround sound by adding the new
channels.
Wide:
Turn on Audyssey DSX
®
processing for front wide
channel expansion.
Height:
Turn on Audyssey DSX
®
processing for front height
channel expansion.
Wides/Heights:
Turns on Audyssey DSX
®
processing for front wide
and front height channel expansion.
Off
(Default):
Do not set “Audyssey DSX
®
”.
0
“Audyssey DSX
®
” can be set when you are using front height speakers or front
wide speakers.
0
“Audyssey DSX
®
” is only valid when using a center speaker.
0
When 2-channel signals are being played back, “Audyssey DSX
®
” cannot be
used.
0
“Audyssey DSX
®
” cannot be configured if the HD Audio source being played
includes Front height and Front wide channels. In this case, the respective
channels are played back using the input signals.
o
Stage Width
Adjust sound stage width when using front wide speakers.
–10 – +10 (Default : 0)
o
Stage Height
Adjust sound stage height when using front height speakers.
–10 – +10 (Default : 0)
Contents Connections Playback Settings Tips Appendix
202
Front panel Display Rear panel Remote Index

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
