Denon AVR-X7200W User Manual

Remote control unit
.
qw
e
w
q
r
t
y
A
p indicator
This is lit when signals are sent from the remote control unit.
B
Zone select button (ZONE SELECT)
These switch the zone (MAIN ZONE, ZONE2, ZONE3) that is operated
through the remote control unit. (v
p. 181, 186)
C
AVR operation button
When preset codes are registered to the remote control unit, press this
button and then operate the menu on the unit.
D
Display
A
Zone select indicators
B
Information indicator
0
This displays “AVR” when operating this unit.
0
This displays the input source name when operating an external
device.
0
This displays “TV” when operating TV.
0
This displays details about the setting on the remote control unit.
E
Device operation buttons (DEVICE X / DEVICE MENU)
These turn the power of external devices on/off and call up menus.
Preset codes need to be registered in order to use these buttons.
(v p. 290)
F
Input source select buttons
These select the input source. (v
p. 87, 181)
Contents
Connections Playback Settings Tips Appendix
28
Front panel Display Rear panel Remote Index

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
