Operations accessible through the option
menu
This can be operated when the “iPod Browse Mode” is set to “On-
Screen”. (v p. 91)
0
“Setting the USB port to use (USB Select)” (v p. 92)
0
“iPod Browse Mode settings” (v p. 91)
0
“Performing repeat playback” (v p. 93)
0
“Performing random playback” (v p. 93)
0
“Adjusting the audibility of dialog and vocals (Dialog
Enhancer)” (v p. 144)
0
“Adjusting the volume of each channel to match the input source
(Channel Level Adjust)” (v p. 145)
0
“Adjusting the tone (Tone)” (v p. 146)
0
“Displaying your desired video during audio playback (Video
Select)” (v p. 147)
0
“Playing the same music in all zones (All Zone Stereo)” (v
p. 149)
Setting the USB port to use (USB
Select)
n
Supported input sources:
iPod/USB
1
Press OPTION.
The option menu screen is displayed.
2
Use ui to select “USB Select”, then press ENTER.
3
Use o p to select the USB port to use.
Front
(Default):
Uses the USB port on the front panel.
Rear: Uses the USB port on the rear panel.
4
Press ENTER.
The display returns to the playback screen.
Contents Connections Playback Settings Tips Appendix
92
Front panel Display Rear panel Remote Index

Denon AVR-X7200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	210 W
HDMI in	8
Audio (L/R) in	7
Composite video in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	3
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	427 mm
Width	434 mm
Height	196 mm
Weight	17800 g
