Page #323 background imageLoading...
Page #323 background image
o
The Internet radio cannot be played back
Symptom Cause / Solution Page
A list of broadcasting
stations is not displayed.
0
The LAN cable is not properly connected, or the network is disconnected. Check the connection status. 81
0
Perform the network diagnostic mode.
Internet Radio cannot be
played.
0
The selected radio station is broadcasting in a format that is not supported by this unit. Formats that can
be played back in this unit are MP3, WMA and AAC.
337
0
The firewall function is enabled on the router. Check the firewall setting.
0
The IP address is not properly set. 274
0
Check the power of the router is on.
0
To obtain the IP address automatically, enable the DHCP server function on the router. Also, set the
DHCP setting to “On” on this unit.
274
0
To obtain the IP address manually, set the IP address and proxy on this unit. 274
0
Some radio stations broadcast silently during some time period. In this case, no audio is output. Wait for a
while and select the same radio station, or select another radio station.
114
Cannot connect to favorite
radio stations.
0
Radio station is not currently in service. Register radio stations in service.
For some radio stations,
“Connection down” is
displayed and station
cannot be connected to.
0
The selected radio station is not in service. Select a radio station in service.
Contents Connections Playback Settings Tips Appendix
323
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X7200W

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X7200W and is the answer not in the manual?

Denon AVR-X7200W Specifications

General IconGeneral
Receiver typeSurround
Input sensitivity200 mV
Audio output channels11.2 channels
Signal-to-Noise Ratio (SNR)102 dB
Power output per channel (1KHz@6 Ohm)190 W
Power output per channel (20-20KHz@8 Ohm)210 W
HDMI in8
Audio (L/R) in7
Composite video in5
Digital audio optical in2
Ethernet LAN (RJ-45) ports1
Component video (YPbPr/YCbCr) in3
12V triggerYes
Speakers connectivity type-
AM band range522 - 1611 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM
Optical drive includedNo
DisplayLCD
Product colorBlack
Audio decodersDolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
AC input voltage230 V
AC input frequency50 Hz
Power consumption (standby)0.1 W
Power consumption (typical)780 W
Weight and Dimensions IconWeight and Dimensions
Depth427 mm
Width434 mm
Height196 mm
Weight17800 g
