Domino F Series User Guide

23
Controls and Indicators
The User Interface, Indicator Lamps and Software icon functions are
described in the following paragraphs:
TouchPanel and Interface
The software is operated via a PC keyboard, TouchPanel or Web
Browser. An entry is confirmed with the left mouse button if PC or Web
browser are used. The optional TouchPanel if connected, allows entry
by touching the tabs and function keys on the screen. An onboard
keyboard is included in the software.
Note: The Web Browser does not support the message editor.
Controls
ON / OFF BUTTON - Starts and stops the controller and PC unit
KEY SWITCH - Starts and stops the Laser Unit (fans and laser tube)
The key switch has three positions:
• “0” Laser off
• “1” Laser ready
• “*” Laser start.
Key switch
On/Off Button
Indicator Lamps
