Ducati MONSTER 1100 S User Manual

109
E
Exhaust system
Equipped with catalytic converter in compliance with Euro 3
emission regulations.
USA model: not catalyzed.
Colour schemes
1100
Ducati anniversary red, code 473.101 (PPG);
Transparent, code 228.880 (PPG);
Red frame with grey wheels.
Silver Matt, code 928D998 (PAL);
Transparent, code 923i1281 (PAL);
Red frame and silver matt wheels.
Gloss black, code 248.514 (PPG);
Transparent, code 228.880 (PPG);
Red frame and silver matt wheels.
1100S
Ducati anniversary red, code 473.101 (PPG);
Transparent, code 228.880 (PPG);
Red frame with gold wheels.
Pearl white, code 490.019 (PPG);
Transparent, code 228.880 (PPG);
Matt black frame with gold wheels.
Electrical system
The main components of the electrical system are:
headlight:
low beam: H7 (12 V-55 W).
main beam: H7 (12 V-55 W).
side light: H6 (12 V-6 W).
Electrical controls on handlebars:
turn signals:
bulb type: RY10W (12 V-10 W).
Horn.
Brake light switches.
Battery, 12 V-10 Ah.
Alternator, 12 V-480 W.
Electronic voltage regulator (rectifier), protected by a 30 A
fuse located next to the ECU (2, fig. 105).
Starter motor, 12 V-0.7 kW.
Tail light and brake light:
LED.
Number plate light:
bulb type: C5W (12 V-5 W).
Notes
To replace the bulbs, refer to the paragraph
“Changing bulbs” on page 89.

Ducati MONSTER 1100 S Specifications

General

Displacement	1078 cc
Torque	103 Nm (76 lb-ft) @ 6000 rpm
Fuel Injection	Siemens electronic fuel injection, 45 mm throttle body
Transmission	6-speed
Frame	Tubular steel Trellis frame
Front Brake	2 x 320 mm discs, 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
Seat Height	810mm (31.9 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Power	70 kW (95 hp) @ 7500 rpm
Front Suspension	43 mm fully adjustable
Rear Suspension	Progressive linkage
Dry Weight	169 kg
Fuel Capacity	15 L
