Ducati MONSTER 1100 S User Manual

94
E
Checking the engine oil level (fig. 100)
Check the engine oil level through the sight glass (1) on the
clutch-side crankcase cover.
Check the oil level with the motorcycle upright and the
engine cold. Allow a few minutes for the oil level to stabilize
after stopping the engine.
The oil level should be between the two marks next to the
sight glass. If the level is below the bottom mark, top up
with SHELL Advance Ultra 4 engine oil.
Remove the oil filler cap (2) and top up until the oil reaches
the required level. Replace the filler cap.
Important
To change the engine oil and filters at the intervals
specified in the maintenance table in the Warranty Booklet,
contact a Ducati dealer or Authorized Service Centre.
Oil viscosity
SAE 15W-50
The other viscosity values shown in the table can be used if
the local average temperature is within the limits specified
for that oil viscosity.
–10
Unigrade
Multigrade
0 10 20 30 40 C
40
20W–40 20W–50
15W–40 15W–50
10W–40
10W–30
10W
20W
20
30
1
2
fig. 100

Ducati MONSTER 1100 S Specifications

General

Displacement	1078 cc
Torque	103 Nm (76 lb-ft) @ 6000 rpm
Fuel Injection	Siemens electronic fuel injection, 45 mm throttle body
Transmission	6-speed
Frame	Tubular steel Trellis frame
Front Brake	2 x 320 mm discs, 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
Seat Height	810mm (31.9 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Power	70 kW (95 hp) @ 7500 rpm
Front Suspension	43 mm fully adjustable
Rear Suspension	Progressive linkage
Dry Weight	169 kg
Fuel Capacity	15 L
