48
E
Throttle twistgrip (fig. 36)
The twistgrip (1) on the right handlebar opens the butterfly
valves in the throttle body. When released, the twistgrip
returns automatically to the initial position (idling speed).
Front brake lever (fig. 36)
Pull the lever (2) towards the twistgrip to operate the front
brake. The system is hydraulically assisted and you only
need to pull the lever gently.
The brake lever has a knob (3) for adjusting the distance
between lever and twistgrip on the handlebar. Lever
distance is adjusted by 10 clicks of the knob (3). Turn the
knob clockwise to move the lever away from twistgrip, or
anti-clockwise to move it closer.
Warning
Before using these controls, read the instructions on
page 62.
2 3
1
fig. 36
