Ducati MONSTER 1100 S User Manual

78
E
Refitting the battery
Important
To install the battery always contact your
Ducati dealer or Authorized Service Centre.
Install the battery in the battery support and secure it
with the elastic retaining strap (19).
Warning
Connect the positive lead (20) to the positive
terminal and the negative lead (21) to the negative terminal,
as shown in the photo.
Insert the bolts (22) in the terminals (20) and (21),
always starting with the positive terminal (red lead).
Warning
Position the leads (20) and (21) as shown in the photo.
Tighten the bolts (22) to a torque of 10 Nm ±10%.
Apply grease around the battery terminals to prevent
corrosion.
22
21
19
20
fig. 77

Ducati MONSTER 1100 S Specifications

General

Displacement	1078 cc
Torque	103 Nm (76 lb-ft) @ 6000 rpm
Fuel Injection	Siemens electronic fuel injection, 45 mm throttle body
Transmission	6-speed
Frame	Tubular steel Trellis frame
Front Brake	2 x 320 mm discs, 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
Seat Height	810mm (31.9 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Power	70 kW (95 hp) @ 7500 rpm
Front Suspension	43 mm fully adjustable
Rear Suspension	Progressive linkage
Dry Weight	169 kg
Fuel Capacity	15 L
