Ducati MONSTER 1100 S User Manual

90
E
Headlight aim (fig. 96)
To check the headlight aim, place the motorcycle upright with
the tyres inflated to the correct pressure and one person sitting
astride the motorcycle. The motorcycle should be perfectly
vertical, with its longitudinal axis at right angles to a wall or
screen at a distance of 10 metres. Draw a horizontal line on the
wall at the height of the centre of the headlight and a vertical
one in line with the longitudinal axis of the motorcycle.
If possible, perform this check in conditions of low ambient
light.
Switch on the low beam headlight:
the upper edge between the dark area and the lit area should
not be above 9/10
th
of the height of the headlamp centre
from the ground.
Notes
This is the procedure specified by Italian regulations
for checking the maximum height of the light beam.
Owners in other countries should adapt this procedure to the
regulations in force in the country where the motorcycle is
used.
10 m
9
10
x
x
fig. 96

Ducati MONSTER 1100 S Specifications

General

Displacement	1078 cc
Torque	103 Nm (76 lb-ft) @ 6000 rpm
Fuel Injection	Siemens electronic fuel injection, 45 mm throttle body
Transmission	6-speed
Frame	Tubular steel Trellis frame
Front Brake	2 x 320 mm discs, 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
Seat Height	810mm (31.9 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Power	70 kW (95 hp) @ 7500 rpm
Front Suspension	43 mm fully adjustable
Rear Suspension	Progressive linkage
Dry Weight	169 kg
Fuel Capacity	15 L
