Electrical Quick Disconnect 6–1
Chapter 6 — Electrical Quick Disconnect (EQD)
Note: Do not use Teon paste on the cord grip threads that screw into the EQD housing.
Disassembling the EQD
1. Loosen the compression nut on the cable tting.
2. Loosen the four screws that hold the insert in the EQD housing.
3. Slide the EQD housing down the power cable.
Figure 6-1
Figure 6-2
