SECTION 5 - PROGRAMMING THE IQ DP-4000 TD 17548B
22
Setpoint Master Record Sheet.
In this section, the available functions are broken into
three categories -- general system (Table 5.B), alarm
(Table 5.C) and optional I/O (Table 5.D). In each table,
the functions are listed in the first column. The second
column of the table identifies the corresponding section
that describes valid setpoint values.
General System Functions Section
System Configuration 3/4 Wire 5.3
Frequency Selection - 50/60 Hz 5.4
Nominal AC Line Voltage setting 5.5
Voltage Transformer Ratio 5.6
Current Transformer Primary 5.7
Phase Sequence - ABC/CBA 5.8
Demand Parameters
Power Demand, Fixed/Sliding
Power Demand Time Interval
Current Demand Time Interval
5.9.1
5.9.2
5.9.3
Energy Setpoints
Reset Energy - Enable/Disable
Energy Resolution
5.10.1
5.10.2
Var/Power Factor sign convention (+ or -) 5.11
PowerNet Network Programmable 5.13
DP-4000/DP-2 Mode 5.14
Table 5.B General System Functions
Alarm Functions Section
Relay Mode 1/Mode 2 5.12.1
Latched/Unlatched Alarm 5.12.2
Activate on Overvoltage 5.12.3
Activate on Undervoltage 5.12.4
Activate on Voltage Phase Loss 5.12.5
Activate on Voltage Phase Unbalance 5.12.6
Activate on Voltage Phase Reversal 5.12.7
Activate on Current Phase Loss 5.12.8
Enable/Disable Alarm 5.12.9
Alarm Delay 5.12.10
Alarm Reset Delay 5.12.11
Overvoltage Detection Level 5.12.12
Undervoltage Detection Level 5.12.13
Voltage Phase Unbalance Detection 5.12.14
Alarm Reset Threshold 5.12.15
Table 5.C Alarm Functions
Optional I/O Functions Section
Discrete Input Setup 5.15.1
Sync Pulse Setpoints 5.15.2
Pulse Initiator/Load Shed
Pulse Initiator Settings, Parameter
Load Shed Range
Load Shed Parameter
Pulse Initiator Settings, Rate Selection
5.15.3.1
5.15.3.2
5.15.3.3
5.15.3.4
Table 5.D Optional I/O Functions
5.2 SETTING SETPOINT SWITCHES
To program the IQ DP-4000, you must determine which
setpoints you want and then record and verify all the
setpoints before starting any entry. Appendix B
contains both a blank Setpoint Master Record Sheet for
recording your setpoint values and, for each function, a
table displaying the required Select Switch and Setpoint
Switches. A Configuration Disk is included with each IQ
DP-4000. This disk contains a Windows95/3.XX tool
that assists you with the proper switch settings;
however, it does not download settings to the meter.
CAUTION
BE CAREFUL WHEN REPROGRAMMING THE IQ
DP-4000. WHEN YOU CHANGE THE VALUES FOR
ONE SETPOINT, BE SURE THAT THE SETPOINT
SWITCHES FOR THAT SELECT SWITCH ARE SET
TO THE PROPER SETTINGS. WHEN YOU PRESS
THE SAVE BUTTON, ALL OF THE SETTINGS FOR
THAT SWITCH CHANGE TO THE NEW SETTINGS.
The Setpoint Switches (S2) are located on a strip at the
rear right portion of the chassis just below the Setpoint
Display LED bank (DS30). Directly below them is the
Rotary Select Switch (S3) and the Save button (S1).
See Figure 2.2 (p.4).
It is essential that all of the desired Setpoint Switch
settings for each Select Switch are recorded in the
Master Setpoint Record Sheet before programming!
To program the Setpoint Switches:
1. Use the Master Setpoint Record Sheet as a
guide for the settings.
2. Turn Select Switch to the desired position (S3.1-F).
3. Set the Setpoint Switches (S2) based on the
information in the Master Setpoint Record Sheet
by sliding the Setpoint Switch to the left to turn the
switch off, or to the right to turn it on.
