IQ DP-4000
SECTION 5 - PROGRAMMING THE IQ DP-4000 TD 17548B
35
Energy S3.D Settings
(Set all 8 S2 switches)
Parameter
S2.2 S2.3 S2.4
Positive Watt-hours on off off
Negative Watt-hours off on off
Positive Var-hours on on off
Negative Var-hours off off on
VA-hours on off on
Invalid Any Other Selection
Table 5.X Pulse Initiator Parameter Selection
Settings
5.15.3.2 Load Shed Settings, Range Selection
Two ranges are associated with the load shed feature: a
Load Shed range and a Restore Load range. Both
ranges are set as a percentage of the nominal values for
the system. When the Load Shed range is exceeded, the
relay activates. This relay remains active until the value
of the selected parameter drops below the Restore Load
range.
The nominal system voltage is explained in Section 5.5
(p.23).
The nominal system current is the value selected for the
CT primary in Section 5.7 (p.24).
The nominal system power is the product of the nominal
system voltage and nominal system current. See Table
5.Y for setting the load shed and restore load ranges.
