Eaton Power Xpert 9395 UPS Installation and Operation Manual 164201764—Rev 14 215
CChhaapptteerr 1100 PPrroodduucctt SSppeecciiffiiccaattiioonnss
1100..11 MMooddeell NNuummbbeerrss
The UPS is housed in a free–standing cabinet with safety shields behind the door and front panels. The UPS is
available in 50 or 60 Hz with various output power ratings.
Models Power Rating Frequency
Power Xpert 9395-1100/1000 (four UPM)
1000 kVA 50/60 Hz
Power Xpert 9395-1100/1100 (four UPM)
1100 kVA 50/60 Hz
Power Xpert 9395-1100/650 (four UPM)
650 kVA 50/60 Hz
Power Xpert 9395-1100/750 (four UPM)
750 kVA 50/60 Hz
Power Xpert 9395-1100/825 (four UPM)
825 kVA 50/60 Hz
1100..22 SSppeecciiffiiccaattiioonnss
The following sections detail the input, output, battery, and environmental specifications for the UPS.
1100..22..11 UUPPSS IInnppuutt
Operating Input Voltage 400 Vac
480 Vac
Operating Input Frequency Range
50/60 Hz
Operating Input Current See Table 5 or Table 6 for four UPM models.
See Table 7 or Table 8 for three UPM models.
Reduced for Generator
Adjustable
Input Current Harmonic Content
5% THD at full load
Power Factor Minimum 0.99
Line Surges 6 kV OC, 3 kA SC per ANSI 62.41 and IEC 801 4
Battery Voltage
480 Vdc
Battery Charging Capacity Configurable per UPM at nominal line voltage:
Up to 120A
Battery Shunt Trip
48 Vdc
