Table 9-5 SMARTCARD status indications
C.rtg SMARTCARD trip: The voltage and/or current rating of the source and destination drives are different
186
Drive rating dependent parameters (parameters with the RA coding) are likely to have different values and ranges with drives of
different voltage and current ratings. Parameters with this attribute will not be transferred to the destination drive by SMARTCARDs
when the rating of the destination drive is different from the source drive and the file is a parameter file. However, drive rating
dependent parameters will be transferred if only the current rating is different and the file is a differences from default type file.
Press the red reset button
Drive rating parameters are:
The above parameters will be set to their default values.
C.Typ SMARTCARD trip: SMARTCARD parameter set not compatible with drive
187
Press the red reset button
Ensure destination drive type is the same as the source parameter file drive type
Table 9-4 Trip conditions
Trip Diagnosis
Parameter Function
2.08 Standard ramp voltage
4.05/6/7, 21.27/8/9 Current limits
4.24 User current maximum scaling
5.07, 21.07 Motor rated current
5.09, 21.09 Motor rated voltage
5.10, 21.10 Rated power factor
5.17, 21.12 Stator resistance
5.18 Switching frequency
5.23, 21.13 Voltage offset
5.24, 21.14 Transient inductance
5.25, 21.24 Stator inductance
6.06 DC injection braking current
6.48 Line power supply loss ride through detection level
Lower display Description Lower display Description
boot A parameter set is being transferred from the
SMARTCARD to the drive during power-up. For further
information, please refer to section 9.2.4 Booting up
from the SMARTCARD on every power up (Pr 11.42 =
boot (4)) .
cArd The drive is writing a parameter set to the SMARTCARD
during power-up.
For further information, please refer to section
9.2.3 Auto saving parameter changes (Pr 11.42 = Auto
(3)) .
