Affinity User Guide 237
Issue Number: 5 www.controltechniques.com
Table 12-12 Losses @ 35°C (95°F) ambient for size 4 to 6 E12/54 drives
Table 12-13 Losses @ 40°C (104°F) ambient for size 4 to 6 E12/54 drives
Model
Drive losses (W) taking into consideration any current derating for the given conditions
3kHz 4kHz 6kHz 8kHz
BA4201-E12/54 520 540 590 640
BA4202-E12/54 610 640 690 750
BA4203-E12/54 810 850 920 990
BA5201-E12/54 1250 1340 1540 1730
BA5202-E12/54 1500 1620 1840 2000
BA4401-E12/54 710 780 910 1050
BA4402-E12/54 880 960 1120 1100
BA4403-E12/54 1070 1160 1110
BA5401-E12/54 1470 1620 1910 2210
BA5402-E12/54 1830 2010 2360 2260
BA6401-E12/54 2300 2560 3090
BA6402-E12/54 2680 3030 3720
BA4601-E12/54 410 470 590 710
BA4602-E12/54 500 570 710 860
BA4603-E12/54 660 750 940 990
BA4604-E12/54 800 910 1010 990
BA4605-E12/54 990 1050 1010 990
BA4606-E12/54 1060 1070 1030 1010
BA5601-E12/54 1820 2130 2090 2050
BA5602-E12/54 2180 2150 2090 2050
BA6601-E12/54 2720 3200 3870
BA6602-E12/54 3180 3730 3870
Model
Drive losses (W) taking into consideration any current derating for the given conditions
3kHz 4kHz 6kHz 8kHz
BA4201-E12/54 520 540 590 640
BA4202-E12/54 610 640 690 750
BA4203-E12/54 750 780 850 910
BA5201-E12/54 1250 1340 1540 1650
BA5202-E12/54 1500 1620 1720 1650
BA4401-E12/54 710 780 910 1050
BA4402-E12/54 880 960 1110 1070
BA4403-E12/54 980 1060 1130 1090
BA5401-E12/54 1470 1620 1640 1570
BA5402-E12/54 1800 1730 1640 1570
BA6401-E12/54 2300 2560 2680
BA6402-E12/54 2680 2760 2610
BA4601-E12/54 410 470 590 710
BA4602-E12/54 500 570 710 860
BA4603-E12/54 660 750 940 970
BA4604-E12/54 800 910 990 970
BA4605-E12/54 990 1020 990 970
BA4606-E12/54 1060 1050 1010 980
BA5601-E12/54 1520 1490 1440 1410
BA5602-E12/54 1520 1490 1440 1410
BA6601-E12/54 2540 2480 2400
BA6602-E12/54 2540 2480 2400
