Emerson Affinity User Manual

Safety
Information
Product
Information
Mechanical
Installation
Electrical
Installation
Getting
Started
Basic
parameters
Running
the motor
Optimization
SMARTCARD
operation
PC tools
Advanced
parameters
Technical
Data
Diagnostics
UL Listing
Information
236 Affinity User Guide
www.controltechniques.com Issue Number: 5
Table 12-11 Losses @ 50°C (122°F) ambient for standard size 1 to 6, size 1 to 3 E12/E54 and size 1 to 3 E12/E66 drives
Model
Drive losses (W) taking into consideration any current derating for the given conditions
3kHz 4kHz 6kHz 8kHz 12kHz 16kHz
BA1201 73 75 78 82 89 96
BA1202 85 87 91 96 104 113
BA1203 107 110 116 121 132 137
BA1204 118 122 129 137
BA2201 155 161 173 186 190
BA2202 190
BA2203 190
BA3201 331 347 380 412 436
BA3202 431 451 480 463 439
BA4201 517 541 589 637
BA4202 611 639 694 750
BA4203 671 701 761 821
BA5201
1250 1340 1540 1730
BA5202
1380 1490 1700 1720
BA1401 66 69 77 75 101 116
BA1402 74 78 88 97 116 135
BA1403 84 90 101 112 135 137
BA1404 102 109 123 137
BA1405 123 134 137
BA1406 137
BA2401 186 190
BA2402 190
BA2403 190
BA3401 384 420 437 423 407 396
BA3402 461 462 439 424 406 396
BA3403 470 456 436 422 405
BA4401 714 781 898 852
BA4402 882 944 898 852
BA4403 877 949 912 875
BA5401 1471 1616 1462 1411
BA5402 1500 1644 1543 1480
BA6401 1942 2118 1939
BA6402 2068 2108 1997
BA3501 127 141 168 196
BA3502 135 150 180 209
BA3503 163 181 218 254
BA3504 197 219 263 306
BA3505 267 296 354 383
BA3506 362 399 390 384
BA3507 405 399 390 384
BA4601 409 470 590 711
BA4602 496 568 712 789
BA4603 660 754 805 789
BA4604 798 831 805 789
BA4605 850 831 805 789
BA4606 871 848 816 797
BA5601 1785 1743 1689 1657
BA5602 1785 1743 1688 1657
BA6601 2084 2036 1978
BA6602 2084 2036 1978
