162 Affinity User Guide
www.controltechniques.com Issue Number: 5
Parameter
Range(
Ú) Default(Ö)
Type
OL RFC OL RFC
5.01 Output frequency {0.11}
±SPEED_FREQ_
MAX Hz
±1,250.0 Hz
RO Bi FI NC PT
5.02 Output voltage 0 to AC_voltage_max V RO Uni FI NC PT
5.03 Output power ±Power_max kW
RO Bi FI NC PT
5.04 Motor rpm {0.10} ±180,000 rpm
RO Bi FI NC PT
5.05 D.C bus voltage 0 to +DC_voltage_max V
RO Uni FI NC PT
5.06 Rated frequency {0.47} 0 to 3,000 Hz 0 to 1,250.0 Hz EUR> 50.0, USA> 60.0 RW Uni US
5.07 Motor rated current {0.46} 0 TO RATED_CURRENT_MAX A RATED_CURRENT_MAX RW Uni RA US
5.08 Rated load rpm / rated speed {0.45} 0 to 180,000 rpm 0.00 to 40,000.00 rpm
EUR>
1,500
USA>
1,800
EUR>
1,450.00
USA>
1,770.00
RW Uni US
5.09 Rated voltage {0.44} 0 to AC_VOLTAGE_SET_MAX V
200V drive: 230
400V drive: EUR> 400
USA> 460
575V drive: 575
690V drive: 690
RW Uni RA US
5.10 Rated power factor {0.43} 0.000 to 1.000 0.850 RW Uni RA US
5.11 Number of motor poles {0.42} Auto to 120 Pole (0 to 60) Auto (0) RW Txt US
5.12 Autotune {0.40} 0 to 2 0 to 4 0 RW Uni NC
5.13
Dynamic V/F / flux optimise
select
{0.09} OFF (0) or On (1)
OFF (0) RW Bit US
5.14 Voltage mode select {0.07}
Ur_S (0), Ur (1),
Fd (2), Ur_Auto (3), Ur_I
(4), SrE (5)
Fd (2) RW Txt US
5.15 Low frequency voltage boost {0.08} 0.0 to 25.0 % of motor rated voltage
Size 1 to 3: 3.0
Size 4 & 5: 2.0
Size 6: 1.0
RW Uni US
5.17 Stator resistance
Size 1 to 5: 0.000 to 65.000
Ω
Size 6: 0.000 to 65.000 x 10 mΩ
0.0 RW Uni RA US
5.18 Maximum switching frequency {0.41} 3 (0), 4 (1), 6 (2), 8 (3), 12 (4), 16 (5) kHz 3 (0) RW Txt RA US
5.19
High stability space vector
modulation
OFF (0) or On (1)
OFF (0)
RW Bit US
5.20 Quasi-square enable RW Bit US
5.21 Field gain reduction
OFF (0) or On (1) OFF (0) RW Bit US
5.23 Voltage offset 0.0 to 25.0 V
0.0 RW Uni RA US
5.24
Transient inductance (
σL
s
)
0.000 to 500.000 mH 0.000
RW Uni RA US
5.25
Stator inductance (L
s
)
0.00 to 5,000.00 mH 0.00 RW Uni RA US
5.26
High dynamic performance
enable
OFF (0) or On (1) OFF (0) RW Bit US
5.27 Enable slip compensation OFF (0) or On (1) On (1) RW Bit US
5.28
Field weakening compensation
disable
OFF (0) or On (1) OFF (0) RW Bit US
5.29 Motor saturation breakpoint 1
0 to 100% of rated flux
50 RW Uni US
5.30 Motor saturation breakpoint 2
75 RW Uni US
5.31 Voltage controller gain 0 to 30 1 RW Uni US
5.32
Motor torque per amp, K
t
0.00 to 500.00
N m A
-1
RO Uni US
5.35
Disable auto switching
frequency change
OFF (0) or On (1) OFF (0) RW Bit US
5.37 Actual switching frequency 3 (0), 4 (1), 6 (2), 8 (3), 12 (4), 16 (5), 6 rEd (6), 12 rEd (7)
RO Txt NC PT
5.40 Spin start boost {0.18} 0.0 to 10.0 1.0 RW Uni US
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
