*For more information, refer to section 11.21.9 Stop modes on page 222.
**For more information, refer to section 11.21.10 Line power supply loss
modes on page 222.
***For more information, refer to section 11.21.11 Catch a spinning
motor on page 224.
****The drive thermal model system normally controls the fan speed,
however the fan can be forced to operate at full speed if this parameter
is set to 1. When this is set to 1 the fan remains at full speed until 10s
after this parameter is set to zero. Note that the fan will only run at full
speed if the drive is not in a UU condition.
Parameter
Range(
Ú) Default(Ö)
Type
OL RFC OL RFC
6.01 Stop mode
COASt (0), rP (1), rP.dcl
(2), dcl (3), td.dcl (4),
diSAbLE (5)
COASt (0), rP (1),
no.rP (2)
rP (1) RW Txt US
6.03 Line power supply loss mode diS (0), StoP (1), ridE.th (2) diS (0) RW Txt US
6.04 Start / stop logic select 0 to 4 4 RW Uni US
6.06 Injection braking level 0 to 150.0%
100.0% RW Uni RA US
6.07 Injection braking time 0.0 to 25.0s
1.0 RW Uni US
6.08
Hold zero speed / Motor pre-
heat enable
{0.38} OFF (0) or On (1) OFF (0) RW Bit US
6.09 Catch a spinning motor {0.39} 0 to 3 0 to 1 0 1 RW Uni US
6.12 Enable stop key
OFF (0) or On (1)
OFF (0) RW Bit US
6.15 Drive enable On (1) RW Bit US
6.16 Date {0.22} 0 to 311299
RW Uni NC PT
6.17 Time {0.23} 0.00 to 23.59
RW Uni NC PT
6.18 Day of week 0 to 6
RO Uni NC PT
6.19 Date/time selection {0.24} 0 to 5 3 RW Uni
6.20 Date format {0.25} Std (0), Std.ds (1), US (2), US.ds (3) EUR> Std (0), USA> US (2) RW Txt US
6.21 Time between filter changes 0 to 30,000 hrs 0 RW Uni US
6.22 Filter change required / change done OFF (0) or On (1) OFF (0) RW Bit PT
6.23 Time before filter change due 0 to 30,000 hrs
RO Uni NC PT PS
6.24 Reset energy meter OFF (0) or On (1) OFF (0) RW Bit NC
6.25 Energy meter: MWh ±999.9 MWh
RO Bi NC PT PS
6.26 Energy meter: kWh ±99.99 kWh
RO Bi NC PT PS
6.27 Energy cost per kWh 0.0 to 600.0
RW Uni NC PT PS
6.28 Running cost ±32,000
RO Bi NC PT
6.29 Hardware enable
OFF (0) or On (1)
RO Bit NC PT
6.30 Sequencing bit: Run forward
OFF (0)
RW Bit NC
6.31 Sequencing bit: Jog forward RW Bit NC
6.32 Sequencing bit: Run reverse RW Bit NC
6.33 Sequencing bit: Forward / reverse RW Bit NC
6.34 Sequencing bit: Run RW Bit NC
6.35 Forward limit switch RW Bit NC
6.36 Reverse limit switch RW Bit NC
6.37 Sequencing bit: Jog reverse RW Bit NC
6.39 Sequencing bit: Not stop RW Bit NC
6.40 Enable sequencer latching RW Bit US
6.41 Drive event flags 0 to 65,535 0 RW Uni NC
6.42 Control word 0 to 32,767 0 RW Uni NC
6.43 Control word enable
OFF (0) or On (1)
OFF (0) RW Bit US
6.44 Active supply
RO Bit NC PT
6.45 Force cooling fan to run at full speed OFF (0) RW Bit US
6.46 Nominal low voltage supply
Size 1: 48V
Size 2, 3 and 200V size 4: 48V to 72V
400V size 4 to 6: 48V to 96V
48 RW Uni PT US
6.47
Disable phase loss detection from input
rectifier
OFF (0) or On (1) OFF (0) RW Bit US
6.48
Line power supply loss ride through
detection level
0 to DC_VOLTAGE_SET_MAX V
200V drive: 205,
400V drive: 410,
575V drive: 540,
690V drive: 540
RW Uni RA US
6.49 Enable date/time in trip log OFF (0) or On (1) On (1) RW Bit US
6.50 Drive comms state drv (0), SLot 1(1), SLot 2 (2)
RO Txt NC PT
6.51 External rectifier not active OFF (0) or On (1) OFF (0) RW Bit
6.52
Motor pre-heat current magnitude
{0.39} 0 to 100 % 0 RW Uni US
6.53
Sleep/wake threshold
{0.15} ±SPEED_FREQ_MAX Hz/rpm 0.0 RW Uni US
6.54
Sleep/wake delay time
{0.16} 0.0 to 250.0 s 10.0 RW Uni US
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
