184 Affinity User Guide
www.controltechniques.com Issue Number: 5
Parameter
Range(
Ú) Default(Ö)
Type
OL RFC OL RFC
12.01 Threshold detector 1 output OFF (0) or On (1)
RO Bit NC PT
12.02 Threshold detector 2 output OFF (0) or On (1)
RO Bit NC PT
12.03 Threshold detector 1 source Pr 1.00 to Pr 50.99 Pr 0.00 RW Uni PT US
12.04 Threshold detector 1 level 0.00 to 100.00 % 0.00 RW Uni US
12.05 Threshold detector 1 hysteresis 0.00 to 25.00 % 0.00 RW Uni US
12.06
Threshold detector 1 output
invert
OFF (0) or On (1) OFF (0) RW Bit US
12.07 Threshold detector 1 destination
Pr 1.00 to Pr 50.99 Pr 0.00
RW Uni DE PT US
12.08 Variable selector 1 source 1 RW Uni PT US
12.09 Variable selector 1 source 2 RW Uni PT US
12.10 Variable selector 1 mode
Select input 1 (0), select input 2 (1), add (2),
subtract (3), multiply (4), divide (5),
time constant (6), linear ramp (7), modulus (8),
powers (9), sectional control (10),
external rectifier monitor (11)
Select input 1 (0) RW Uni US
12.11 Variable selector 1 destination Pr 1.00 to Pr 50.99 Pr 0.00 RW Uni DE PT US
12.12 Variable selector 1 output ±100.00 %
RO Bi NC PT
12.13
Variable selector 1 source 1
scaling
±4.000 1.000
RW Bi US
12.14
Variable selector 1 source 2
scaling
RW Bi US
12.15 Variable selector 1 control 0.00 to 100.00 s 0.00 RW Uni US
12.23 Threshold detector 2 source Pr 1.00 to Pr 50.99 Pr 0.00 RW Uni PT US
12.24 Threshold detector 2 level 0.00 to 100.00 %
0.00
RW Uni US
12.25 Threshold detector 2 hysteresis 0.00 to 25.00 % RW Uni US
12.26
Threshold detector 2 output
invert
OFF (0) or On (1) OFF (0) RW Bit US
12.27 Threshold detector 2 destination
Pr 1.00 to Pr 50.99 Pr 0.00
RW Uni DE PT US
12.28 Variable selector 2 source 1 RW Uni PT US
12.29 Variable selector 2 source 2 RW Uni PT US
12.30 Variable selector 2 mode
Select input 1 (0), select input 2 (1), add (2),
subtract (3), multiply (4), divide (5),
time constant (6), linear ramp (7), modulus (8),
powers (9), sectional control (10),
external rectifier monitor (11)
Select input 1 (0) RW Uni US
12.31 Variable selector 2 destination Pr 1.00 to Pr 50.99 Pr 0.00 RW Uni DE PT US
12.32 Variable selector 2 output ±100.00 %
RO Bi NC PT
12.33
Variable selector 2 source 1
scaling
±4.000 1.000
RW Bi US
12.34
Variable selector 2 source 2
scaling
RW Bi US
12.35 Variable selector 2 control 0.00 to 100.00 s 0.00 RW Uni US
12.40 Brake release indicator OFF (0) or On (1)
RO Bit NC PT
12.41 Brake controller enable dis (0), rEL (1 ), d IO (2), USEr (3) dis (0) RW Txt US
12.42 Upper current threshold 0 to 200 %
50 RW Uni US
12.43 Lower current threshold 0 to 200 % 10 RW Uni US
12.44 Brake release frequency
0.0 to 20.0 Hz
1.0 RW Uni US
12.45 Brake apply frequency / speed 0 to 200 rpm 2.0 5 RW Bit US
12.46
OL> Pre-brake release delay
0.0 to 25.0 s
1.0
RW Uni US
RFC> Brake apply speed delay
1.0
12.47 Post brake release delay 1.0 RW Uni US
12.48 Brake apply delay
0.0 to 25.0 s 1.0 RW Uni US
The brake control functions are provided to allow well co-ordinated operation of an external brake with the drive. While both hardware
and software are designed to high standards of quality and robustness, they are not intended for use as safety functions, i.e. where a
fault or failure would result in a risk of injury. In any application where the incorrect operation of the brake release mechanism could result
in injury, independent protection devices of proven integrity must also be incorporated.
