Affinity User Guide 197
Issue Number: 5 www.controltechniques.com
SM-I/O Plus parameters
*See trip SLX.Er, Automation (I/O Expansion) module category on page 257.
Parameter
Range(
Ú) Default(Ö)
Type
x.01 Solutions Module ID 0 to 599 201 RO Uni PT US
x.03 T4 digital I/O 3 state
OFF (0) or On (1)
RO Bit NC PT
x.04 T6 digital input 4 state RO Bit NC PT
x.05 T7 digital input 5 state RO Bit NC PT
x.06 T8 digital input 6 state RO Bit NC PT
x.07 Relay 1 state RO Bit NC PT
x.08 Relay 2 state RO Bit NC PT
x.09 T2 digital I/O 1 state RO Bit NC PT
x.10 T3 digital I/O 2 state RO Bit NC PT
x.11 T2 digital I/O 1 invert
OFF (0)
RW Bit US
x.12 T3 digital I/O 2 invert RW Bit US
x.13 T4 digital I/O 3 invert RW Bit US
x.14 T6 digital input 4 invert RW Bit US
x.15 T7 digital input 5 invert RW Bit US
x.16 T8 digital input 6 invert RW Bit US
x.17 Relay 1 invert RW Bit US
x.18 Relay 2 invert RW Bit US
x.20 Digital I/O read word 0 to 511
RO Uni NC PT
x.21
T2 digital I/O 1 source/
destination
Pr 0.00 to Pr 50.99 Pr 0.00
RW Uni DE PT US
x.22
T3 digital I/O 2 source/
destination
RW Uni DE PT US
x.23
T4 digital I/O 3 source/
destination
RW Uni DE PT US
x.24 T6 digital input 4 destination RW Uni DE PT US
x.25 T7 digital input 5 destination RW Uni DE PT US
x.26 T8 digital input 6 destination RW Uni DE PT US
x.27 Relay 1 source RW Uni PT US
x.28 Relay 2 source RW Uni PT US
x.29 Input polarity select
OFF (0) or On (1)
On (1) (positive logic) RW Bit PT US
x.31 T2 digital I/O 1 output select
OFF (0)
RW Bit US
x.32 T3 digital I/O 2 output select RW Bit US
x.33 T4 digital I/O 3 output select RW Bit US
x.40 Analog input 1 ±100.0%
RO Bi NC PT
x.41 Analog input 1 scaling 0 to 4.000 1.000 RW Uni US
x.42 Analog input 1 invert OFF (0) or On (1) OFF (0) RW Bit US
x.43 Analog input 1 destination Pr 0.00 to Pr 50.99 Pr 0.00 RW Uni DE PT US
x.44 Analog input 2 ±100.0%
RO Bi NC PT
x.45 Analog input 2 scaling 0.000 to 4.000 1.000 RW Uni US
x.46 Analog input 2 invert OFF (0) or On (1) OFF (0) RW Bit US
x.47 Analog input 2 destination
Pr 0.00 to Pr 50.99 Pr 0.00
RW Uni DE PT US
x.48 Analog output 1 source RW Uni PT US
x.49 Analog output 1 scaling 0.000 to 4.000 1.000 RW Uni US
x.50 Solutions Module error status* 0 to 255
RO Uni NC PT
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
