Emerson Affinity User Manual

Safety
Information
Product
Information
Mechanical
Installation
Electrical
Installation
Getting
Started
Basic
parameters
Running
the motor
Optimization
SMARTCARD
operation
PC tools
Advanced
parameters
Technical
Data
Diagnostics
UL Listing
Information
200 Affinity User Guide
www.controltechniques.com Issue Number: 5
SM-I/O Lite parameters
*See trip SLX.Er, Automation (I/O Expansion) module category on page 257.
Parameter
Range(
Ú) Default(Ö)
Type
SM-I/O
Lite Timer
x.01 Solutions Module ID 0 to 599 SM-I/O Lite: 207 RO Uni PT US 99
x.02 Solutions Module software version 0.00 to 99.99 RO Uni NC PT 99
x.03 Current loop loss indicator
OFF (0) or On (1)
RO Bit NC PT 99
x.04 T5 digital input 1 state RO Bit NC PT 99
x.05 T6 digital input 2 state RO Bit NC PT 99
x.06 T7 digital input 3 state RO Bit NC PT 99
x.07 Relay 1 state RO Bit NC PT 99
x.14 T5 digital input 1 invert
OFF (0)
RW Bit US 99
x.15 T6 digital input 2 invert RW Bit US 99
x.16 T7 digital input 3 invert RW Bit US 99
x.17 Relay 1 invert RW Bit US 99
x.20 Digital I/O read word 0 to 255 RO Uni NC PT 99
x.24 T5 digital input 1 destination
Pr 0.00 to Pr 50.99 Pr 0.00
RW Uni DE PT US 99
x.25 T6 digital input 2 destination RW Uni DE PT US 99
x.26 T7 digital input 3 destination RW Uni DE PT US 99
x.27 Relay 1 source RW Uni PT US 99
x.38 Analog input 1 mode
0-20 (0), 20-0 (1), 4-20.tr (2),
20-4.tr (3), 4-20 (4), 20-4 (5),
VOLt(6)
0-20 (0) RW Txt US 99
x.39 Analog output mode
0-20 (0), 20-0 (1), 4-20 (2), 20-4 (3),
VOLt (4)
0-20 (0) RW Txt US
99
x.40 Analog input 1 ±100.0% RO Bi NC PT 99
x.41 Analog input 1 scaling 0 to 4.000 1.000 RW Uni US 99
x.42 Analog input 1 invert OFF (0) or On (1) OFF (0) RW Bit US 99
x.43 Analog input 1 destination
Pr 0.00 to Pr 50.99 Pr 0.00
RW Uni DE PT US 99
x.48 Analog output 1 source RW Uni PT US 99
x.49 Analog output 1 scaling 0.000 to 4.000 1.000 RW Uni US 99
x.50 Solutions Module error status* 0 to 255 RO Uni NC PT 99
x.51 Solutions Module software sub-version 0 to 99 RO Uni NC PT 99
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
