Affinity User Guide 211
Issue Number: 5 www.controltechniques.com
Table 11-7 Applications module parameters
Parameter
Range(
Ú) Default(Ö)
Type
x.01 Solutions Module ID 0 to 599 RO Uni PT US
x.02 Solutions Module software version 0.00 to 99.99
RO Uni NC PT
x.03 DPL program status None (0), Stop (1), Run (2), Trip (3)
RO Txt NC PT
x.04 Available system resource 0 to 100
RO Uni NC PT
x.05 RS485 address 0 to 255 11 RW Uni US
x.06 RS485 mode 0 to 255 1 RW Uni US
x.07 RS485 baud rate
300 (0), 600 (1), 1200 (2), 2400 (3), 4800 (4),
9600 (5), 19200 (6), 38400 (7), 57600 (8),
115200 (9) baud
4800 (4) RW Txt US
x.08 RS485 Turnaround delay 0 to 255 ms 2 RW Uni US
x.09 RS485 Tx enable delay 0 to 1 ms 0 RW Uni US
x.10 DPL Print Routing SYPT: OFF (0), RS485: On (1) SYPT: OFF (0) RW Bit US
x.11 Clock task scheduling (ms) 0 to 200 10 RW Uni US
x.12 POS task scheduling rate
dISAbLEd (0), 0.25 ms (1), 0.5 ms (2), 1 ms (3),
2 ms (4), 4 ms (5), 8 ms (6)
dISAbLEd (0) RW Txt US
x.13 Enable autorun
OFF (0) or On (1)
On (1) RW Bit US
x.14 Global run time trip enable
OFF (0)
RW Bit US
x.15 Disable reset on trip cleared RW Bit US
x.16 Encoder data update rate 0 to 3 0 RW Uni US
x.17 Enable parameter over range trips
OFF (0) or On (1) OFF (0)
RW Bit US
x.18 Watchdog enable RW Bit US
x.19 Save request RW Bit NC
x.20 Enable power down save RW Bit US
x.21
Enable menu 20 save and
restore
RW Bit US
x.22 CTNet Token Ring ID
0 to 255
0RWUniUS
x.23 CTNet node address 0RWUniUS
x.24 CTNet baud rate 5.000 (0), 2.500 (1), 1.250 (2), 0.625 (3) 2.500 (1) RW Txt US
x.25 CTNet sync setup 0,000 to 9,999 0,000 RW Uni US
x.26
CTNet easy mode - first cyclic
parameter destination node
0 to 25,503
0
RW Uni US
x.27
CTNet easy mode - first cyclic source
parameter
0 to 9,999 RW Uni US
x.28
CTNet easy mode - second cyclic
parameter destination node
0 to 25,503 RW Uni US
x.29
CTNet easy mode - second cyclic
source parameter
0 to 9,999 RW Uni US
x.30
CTNet easy mode - third cyclic
parameter destination node
0 to 25,503 RW Uni US
x.31
CTNet easy mode - third cyclic source
parameter
0 to 9,999 RW Uni US
x.32
CTNet easy mode set-up - Transfer
slot 1 destination parameter
0 to 9,999 RW Uni US
x.33
CTNet easy mode set-up - Transfer
slot 2 destination parameter
0 to 9,999 RW Uni US
x.34
CTNet easy mode set-up - Transfer
slot 3 destination parameter
0 to 9,999 RW Uni US
x.35 CTNet sync event task ID
Disabled (0), Event (1), Event1 (2), Event2 (3),
Event3 (4)
Disabled (0) RW Txt US
x.36 CTNet diagnostic parameter -3 to +32,767
RO Uni NC PT
x.37 Reject download if drive enabled
OFF (0) or On (1) OFF (0)
RW Bit US
x.38 APC run-time trip RW Bit US
x.39 Inter-module synchronization status 0 to 3
0
RO Uni NC
x.41 Indexer control 0 to 255 RW Uni NC
x.42 Pass freeze through drive
OFF (0) or On (1) OFF (0)
RW Bit US
x.43 Freeze invert RW Bit US
x.44 Task priority level 0 to 255 0 RW Uni US
x.45 User set-up parameter 1 0 to 65535
RO Uni NC
x.46 User set-up parameter 2 -32,768 to +32,767 RO Uni NC
x.47 User set-up parameter 3 0 to 255 RO Uni NC
x.48 DPL line number in error 0 to 2,147,483,647
0
RO Uni NC PT
x.49 User program ID -32,768 to +32,767 RO Bi NC PT
x.50 Solutions Module error status* 0 to 255
RO Uni NC PT
x.51
Solutions Module software sub-version 0 to 99 RO Uni NC PT
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
