Affinity User Guide 231
Issue Number: 5 www.controltechniques.com
Table 12-4 Maximum permissible continuous output current @ 50°C (122°F) ambient for size 1 to 6 standard, size 1 to 3 E12/E54 drives and
size 1 to 3 E12/E66 drives
For the definition of ambient temperature, see section 3.7 Enclosure design and drive ambient temperature on page 49.
Model
Maximum permissible continuous output current (A) for the following switching frequencies
3kHz 4kHz 6kHz 8kHz 12kHz 16kHz
BA1201 5.2
BA1202 6.8
BA1203 9.6 9.0
BA1204 11.0 10.9 9.5 8.3
BA2201 15.5 13.5 11.5
BA2202 19.7 18.9 17.3 15.9 13.5 11.5
BA2203 19.5 18.6 17.2 15.8 13.4 11.5
BA3201 42.0 38.2
BA3202 54.0 52.8 47.0 38.2
BA4201 68.0
BA4202 80.0
BA4203 87.4
BA5201 130.0
BA5202 154.0 143.2
BA1401 2.8
BA1402 3.8
BA1403 5.0 3.9
BA1404 6.9 5.1 3.9
BA1405 8.8 7.3 6.0 4.2 3.1
BA1406 10.1 9.0 7.3 6.0 4.2 3.1
BA2401 15.3 14.2 11.8 10.0 7.3 5.5
BA2402 15.7 14.2 11.8 10.0 7.3 5.5
BA2403 16.8 15.0 12.2 10.1 7.1
BA3401 35.0 31.0 25.8 18.7 14.2
BA3402 43.0 39.5 31.6 26.0 18.5 13.8
BA3403 44.5 39.5 31.6 26.0 18.5
BA4401 68.0 66.8 54.9
BA4402 83.0 81.6 66.8 54.9
BA4403 86.5 86.2 71.3 59.3
BA5401 138 105.9 87.4
BA5402 141 140 112 92
BA6401 191.5 190.1 147.6
BA6402 198.4 180.6 138.1
BA3501 5.4
BA3502 6.1
BA3503 8.4
BA3504 11.0
BA3505 16.0 14.7
BA3506 22.0 17.8 14.7
BA3507 24.6 22.0 17.8 14.7
BA4601 22.0
BA4602 27.0 24.7
BA4603 36.0 30.7 24.7
BA4604 43.0 39.6 30.7 24.7
BA4605 45.6 39.5 30.7 24.7
BA4606 51.9 44.9 34.7 27.7
BA5601 83 69 51 40
BA5602 83 69 51 40
BA6601 98 81 59
BA6602 98 81 59
NOTE
