Emerson Dixell XC15CX User Manual

1592001530 XC15-35CX EN r1.2 11.04.2017 XC15-35CX 14/40
Manual load restart:
if par. r1F=rSt, press this button to restart the loads and previously
stopped due to safety alarm
ON-OFF:
if par. r2F=onF, keep this button pressed for 3 sec to switch ON and
OFF the instrument
SERVICE / CLOCK: to enter CLOCK and SERVICE menu
STORED ALARMS:
it gives access to the stored alarms
KEY COMBINATION
UP + DOWN
To lock and unlock the keyboard
SET + DOWN
To enter the programming parameter menu
SET + UP
To exit from INFO and ALARM menu and from programming parameter
menu
7.3 ICONS
LED
STATUS
MEANING
ON
Unit of measurement for temperature is Celsius degrees
ON
Unit of measurement for temperature is Fahrenheit degrees
ON
Unit of measurement for pressure is Bar
ON
Unit of measurement for pressure is PSI
ON
Relay output oA1 enabled
BLINKING
Delay in relay output oA1 activation
ON
Relay output oA2 enabled
BLINKING
Delay in relay output oA2 activation
ON
Relay output oA3 enabled
BLINKING
Delay in relay output oA3 activation
ON
Analogue output active
ON
(SER) Service menu
BLINKING
(SER) Outputs in service mode
ON
(ALR) Alarm active
ON
(MEM) At least an alarm present into memory
BLINKING
(MEM) A new alarm is occured and need to be checked
ON
Energy Saving mode active
ON
Real Time Clock Menu
8. SET-POINT MENU
8.1 SETPOINTS VISUALIZATION
1. Press and release the SET button
2. SUCTION: the display will show the label St1 [Compressor setpoint]
3. Press the SET button again to show the value of St1
