1592001530 XC15-35CX EN r1.2 11.04.2017 XC15-35CX 24/40
Add
Delay for temperature/pressure alarm activation on condenser: 0 to 255 min
HFC
Compressor stopped in case of any HAF alarm: n; Y
HFL
Compressor capacity limitation in case of any HAF alarm: 0 to 80%, if HFL=0
the compressor will be stopped.
dHF
Delay before stopping the compressor in case of any HAF alarm: 1 to 999 sec
PnF
Max number HAF alarms before stopping the regulation: (0 to 15) after
detecting PnF alarms of the HAF type in an interval of time PiF, the regulation will
be stopped (if HFC=Y).
PiF
Interval of time to count the number of HAF alarms events: 0 to 999 min. With
PEi=0 this function is disabled.
FUP
Ventilators up time before maintenance: (10 to 9990 hours, res. 10 hours) after
reaching the preset number of hours, the device will show the maintenance warning.
FPr
Number of ventilators active when probe FPb is in error: 0 to 2
15.11 DYNAMIC SETPOINT
dSP
Probe used for dynamic set point function: nP; P1; P2; P3; P4
dSS
Dynamic setpoint value:
- NTC10k  -40 to 110°C; -40 to 230°F
- NTC86k  -40 to 180°C; -40 to 356°F
- PT1000  -40 to 180°C; -40 to 356°F
dSb
Regulation band for dynamic setpoint: -50 to 50°C; -90 to 90°F
dSd
Differential for dynamic SETPOINT: -50 to 50°C; -90 to 90°F
15.12 ANALOGUE OUTPUT (OAN)
AoP
Analogue output reference probe (valid if oAn=PrP): nP; P1; P2; P3; P4
LAo
Lower limit for analogue output: input value (AoP) corresponding to the minimum
analogue output value (Ao1)
- NTC10k  -40 to 110°C; -40 to 230°F
- NTC86k  -40 to 180°C; -40 to 356°F
- PT1000  -40 to 180°C; -40 to 356°F
- 0-5  0.0 to 51.0 bar; 0 to 750 PSI
UAo
Upper limit for analogue output: input value (AoP) corresponding to the minimum
analogue output value (Ao2)
- NTC10k  -40 to 110°C; -40 to 230°F
- NTC86k  -40 to 180°C; -40 to 356°F
- PT1000  -40 to 180°C; -40 to 356°F
- 0-5  0.0 to 51.0 bar; 0 to 750 PSI
Ao1
Minimum value for analogue output: 0 to 10Vdc
Ao2
Maximum value for analogue output: Ao1 to 10Vdc
Aot
Interval of time with analogue output at maximum time: 0 to 255sec
- If oAn=PrP: after pasing toA value
- If oAn=EFn: after start-up
SAo
Safety value for analogue output used in case of probe error (valid if
oAn=PrP): 0 to 100%
toA
Differential for analogue output: 0 to 100%
15.13 BUMP FUNCTION
bMP
BUMP function enabled: n; Y
bon
Compressor ON time during BUMP function: 1 to 15 sec
boF
Compressor OFF time during BUMP function: 1 to 15 sec
nub
Number of cycles for BUMP function: 1 to 15
