1592001530 XC15-35CX EN r1.2 11.04.2017 XC15-35CX 33/40
During preset intervals of time the maximum allowed speed will be fixed to par. FSS (in
percentage).
The silent mode will be deactivated as soon as an alarm is detected.
17. SPECIAL FUNCTIONS
17.1 DYNAMIC SET-POINT
This function is used to move the condensing regulation band (par. St2 and HY2) and use
another (external) temperature (par. dSP).
External temperature probe
Regulation band for dynamic SET-POINT
Differential for dynamic SET-POINT
17.1.1 HOW IT WORKS
When the temperature measured by the probe dSP goes over the dSS SET-POINT, this
function will be activated. The value of the dynamic SET-POINT increases proportionally from 0
to dSd when the temperature measured by the probe dSP=dSS+dSb. The value of the dynamic
SET-POINT is continuously added to the value of the ventilator set point (St2).
17.2 ANALOGUE REPEATER
When enabled (par. oAn=PrP) the analogue output will act as a proportional repeater following
the value measured from the variable set in the par. AoP.
Lower value for input scale
Upper value for input scale
Differential for analogue output
Minimum value for analogue output
Maximum value for analogue output
Time with analogue output at maximum after start-up
