1592001530 XC15-35CX EN r1.2 11.04.2017 XC15-35CX 19/40
5. Remove the key HOT-KEY
NOTE: the "Err" message on the display indicates that the operation is not successful (transfer
error). In this case, turn off and then on again the device in order to restart the operation or
remove the HOT-KEY to abort the operation.
15. PARAMETERS
15.1 REGULATION SET-POINT
SETPOINT 1 for compressor regulation (suction line): LS1 to US1
SETPOINT 2 for ventilator regulation (condensing line): LS2 to US2
Regulation band for SETPOINT 1:
- P1C=ntC 0.1 to 25.5°C; 1 to 45°F
- P1C=0-5 0.1 to 9.9 bar; 1 to 999 PSI
Minimum value for SETPOINT 1:
- P1C=NTC: -40.0°C to US; -40°F to US
- P1C=0-5: P1i to US [bar, PSI]
Maximum value for SETPOINT 1:
- P1C=NTC: LS to 110.0°C; LS to 230°F
- P1C=0-5: LS to P1E [bar, PSI]
Regulation band for SETPOINT 2:
- P2C=ntC 0.1 to 25.5°C; 1 to 45°F
- P2C=0-5 0.1 to 9.9 bar; 1 to 999 PSI
Minimum value for SETPOINT 2:
- P2C=NTC: -40.0°C to US; -40°F to US
- P2C=0-5: P1i to US [bar, PSI]
Maximum value for SETPOINT 2:
- P2C=NTC: LS to 110.0°C; LS to 230°F
- P2C=0-5: LS to P1E [bar, PSI]
Offset for SETPOINT 1 when in energy savin mode:
- P1C=ntC -50.0 to 50.0°C; -90 to 90°F
- P1C=0-5 -20.0 to 20.0 bar; -300 to 300 PSI
Offset for SETPOINT 2 when in energy saving mode:
- P2C=ntC -50.0 to 50.0°C; -90 to 90°F
- P2C=0-5 -20.0 to 20.0 bar; -300 to 300 PSI
Filter for pressure probe reading enabled: n=filter disabled; Y=filter enabled
Coefficient for pressure probe reading filter: 0 to 100, 100=filter disabled;
mEd=avarage value during last period (tdG)
15.3 PROBE CONFIGURATION
15.3.1 Suction Probe Configuration:
Suction probe P1: n=not available (compressor regulation disabled); Y=available
(compressor regulation enabled)
Suction transducer configuration:
0-5= ratiometric transducer (5.0Vdc)
ntC=temperature probe NTC 10k
Start of scaling for pressure transducer P1: (-1.5 to P1E bar; -21 to P1E PSI) it is
the pressure value measured from sensor corresponding to 0.5Vdc
