Interval of time with compressor OFF before activating the BUMP function: 0.0
to 23h50min, res. 10 min
Anti-resonance function enabled: n; Y
Lower boundary of the first skipped band:
- If frequency output: 0 to SE1 Hz
- If voltage output: 0.0 to SE1 V
Upper boundary of the first skipped band:
- If frequency output: SE1 to 500Hz
- If voltage output: SE1 to 10V
Lower boundary of the second skipped band:
- If frequency output: 0 to SE2 Hz
- If voltage output: 0.0 to SE2 V
Upper boundary of the second skipped band:
- If frequency output: SE2 to 500Hz
- If voltage output: SE2 to 10V
Lower boundary of the third skipped band:
- If frequency output: 0 to SE3 Hz
- If voltage output: 0.0 to SE3 V
Upper boundary of the third skipped band:
- If frequency output: SE3 to 500Hz
- If voltage output: SE3 to 10V
15.15 OUTPUT CONFIGURATION
Alarm relay deactivation: n; Y
Relay output (16 A):
- nu=output not used
- onF=output activated when controller in ON
- ALr=alarm output
- Fn1=ventilator output
- dGt=Digital Scroll output
- d4d=Digital Stream (4 cylinder) output
- inV=Inverter output
- CP1=ONOFF compressor output
Relay output (5 A) (only for XC35CX models):
- nu=output not used
- onF=output activated when controller in ON
- ALr= alarm output
- Fn2= ventilator output
- CP2= ONOFF compressor output
TRIAC output (MAX 2.2 A):
- nu=output not used
- onF=output activated when controller in ON
- ALr=alarm output
- PCF=phase-cut controlled output
- dGt=Digital Scroll discharge valve control
- d4d= Digital Stream discharge valve control
