1592001530 XC15-35CX EN r1.2 11.04.2017 XC15-35CX 40/40
20. TECHNICAL SPECIFICATIONS
Housing: self-extinguishing ABS
Case: frontal 32x74 mm; depth 60mm
Mounting: panel mounting in a 71x29mm panel cut-out
Protection: IP20; Frontal protection: IP65
Connections: quick connect tabs terminal block 2.5 mm
2
wiring
Power supply: according to the model
24VAC, ±10%
110AC 10%, 50/60Hz
230VAC 10%, 50/60Hz
Power absorption: 3.5VA max
Display: 3 digits, red LED, 14.2 mm high
Analogue inputs: up to 4 NTC10k / NTC86k or PT1000 probes, up to 2 ratiometric 0…5Vdc
Digital inputs: up to 3 free voltage contacts
Outputs:
oA1: SPST 16(8) A, 250VAC
oA2: SPST 5(2) A, 250VAC (only for XC35CX)
oA3 (Triac): (depending on the model) 0,5A@250Vac or @120Vac; 1,5A@24Vac
oAn (0-10Vdc): max 20mA
Buzzer: optional
Data storing: on the non-volatile memory (EEPROM)
Internal clock back-up: 24 hours
Kind of action: 1B
Pollution degree: 2
Software class: A
Rated impulsive voltage: 2500V
Overvoltage Category: II
Operating temperature: -10 to 55°C (14 to 131°F)
Storage temperature: -20 to 85°C (-4 to 185°F)
Relative humidity: 20 to 85% (no condensing)
Measuring and regulation range:
NTC10k: -40 to 110°C (-40 to 230°F)
NTC86k: -40 to 180°C (-40 to 356°F)
PT1000: -40 to 180°C (-40 to 356°F)
Resolution: 0.1°C or 1°C or 1°F (selectable), 0.1 bar, 1PSI
Accuracy (ambient temp. 25°C): ±0.7°C ±1 digit
