Installation Guide
29
Installation Procedure
Make sure to follow the steps below to install the setting plate. If these steps are not followed, the product
could fall and cause personal injury or property damage.
Warning
Do not use adhesives, lubricants, or oils to install or adjust the setting plate. If you use adhesives to prevent
the screws from loosening or things such as lubricants or oils on the slide plate fixing part of the projector,
the case may crack and cause the projector to fall, resulting in personal injury or property damage.
Assemble the parts
a
Connect the plate and frames (x2) and secure with the M4 x 12 mm bolts (x5) supplied
To Next Page
