Installation Guide
35
Attaching the setting plate to the wall plate
a
Insert the hexagonal axis into the setting plate
b
Mount the setting plate to the wall plate
Insert the top of the hexagonal axis into the wall plate, and then insert it into the slot at the bottom.
Caution
Take care not to trap the cables between the setting plate and wall plate.
To Next Page
