Adjusting the Image
34
Adjust using the gamma adjustment graph
Make adjustments while viewing the gamma adjustment graph for the image being projected.
a
Use the buttons to select the
part you want to adjust from the
graph.
b
Use the buttons to
adjust the brightness, and then press
the
button to confirm the
selection.
Adjusting the RGB (Offset/Gain)
For the image's brightness, you can adjust the dark areas (Offset) and the bright areas (Gain) for R (red), G
(green), and B (blue). The image becomes brighter when moved to the right (positive) and darker when moved
to the left (negative).
Offset
When the image is made brighter, shading for the darker sections is more vividly expressed.
When the image is made darker, the image appears more full-bodied but shading for the
darker sections is harder to distinguish.
Gain
When the image is made brighter, the bright sections become whiter and shading is lost.
When the image is made darker, shading for the bright sections is more vividly expressed.
The menu is displayed in the following order.
Image - Advanced - RGB
Use the
buttons to select the item, and then
use the
buttons to make the adjustments.
c
Press the button to return the adjustments to their default values.
Abs. Color Temp.
You can adjust the overall tint of the image. Make adjustments if the image is a little too blue or too red and
so on.
The menu is displayed in the following order.
Image - Abs. Color Temp.
Use the
buttons to make adjustments.
Blue tints grow stronger as the value is increased, and red
tints grow stronger as the value is reduced.
