Epson EH-TW9100W User Manual

Configuration Menu
70
Signal menu
Function Menu/Settings Explanation
3D Setup
*1
3D Display On, Off Enables or disables the 3D Display function.
s p.45
2D-to-3D Conver-
sion
Off, Weak, Medium,
Strong
Sets the strength of the 3D effect when convert-
ing 2D to 3D images.
s p.52
3D Format Auto, Side by Side,
Top and Bottom, 2D
Sets the 3D format for the input signal. If set to
Auto, the format is recognized automatically.
3D Depth -10 - 10 Sets the depth for the 3D image.
Diagonal Screen
Size
60 - 300 Sets the projection size for the 3D image. By
matching this to the actual size, you can achieve
the optimum 3D effect.
3D Brightness Low, Medium, High Sets the brightness for the 3D image.
Inverse 3D Glasses Yes, No Reverses the synchronization timing for the left/
right shutters on the 3D Glasses and the left/right
images. Enable this function if the 3D effect is not
displayed correctly.
3D Viewing Notice On, Off Turns the notice that appears when viewing 3D
content on or off.
Aspect
*2
Auto, Normal, Full, Zoom, Wide, Anamor-
phic Wide
*7
, Horiz. Squeeze
*7
Selects the aspect mode. s p.32
Zoom Size
*2
(Available when Aspect or Zoom are set.)
Any parts at the top or bottom that cannot be
seen when Zoom is set are squeezed vertically
to fit on the screen. The higher you set this value
the more the image is squeezed vertically.
Zoom Caption
Pos.
*2
(Available when Aspect or Zoom are set.)
If subtitles are not completely visible when view-
ing images with subtitles at the bottom, you can
adjust the position of the image up or down until
the subtitles become visible.
Tracking
*2 *3
Varies depending on the input signal. Adjusts computer images when vertical stripes
appear in the images.
Sync.
*2 *3
0 - 31 Adjusts computer images when flickering, fuzzi-
ness, or interference appear in the images.
•
Adjusting the Brightness, Contrast, or Sharp-
ness may cause flickering or blurriness.
•
Adjusting the synchronization after adjusting
tracking allows for more accurate adjustments.
Position
*2 *4
Adjusts the display position up, down, left, and
right when a part of the image is missing so that
the whole image is projected.

Epson EH-TW9100W Specifications

General

RS-232 ports	1
Matrix size	0.74 \
White light output	2400 ANSI lumens
Projection distance	- m
Projection technology	3LCD
Screen size compatibility	30 - 300 \
Projection distance (tele)	1.9 - 19.2 m
Projection distance (wide)	0.9 - 9 m
Projector native resolution	1080p (1920x1080)
Keystone correction, vertical	-30 - 30 °
Full HD	Yes
Color modes (2D)	Dynamic, Cinema
Supported 3D formats	Side by side, Top and bottom, Frame packing
Analog signal format system	-
Focus	Manual
Focal length range	23 - 47 mm
Aperture range (F-F)	2 - 3.17
Vertical lens shift range	-96.3 - 96.3 %
Horizontal lens shift range	-47.1 - 47.1 %
Lamp type	E-TORL
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
Serial interface type	RS-232
USB 2.0 ports quantity	0
Noise level	- dB
Country of origin	China
2D/3D frequency image	240/480 Hz
Noise level (economic mode)	22 dB
Placement	Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.39 W
Power consumption (typical)	340 W
Power consumption (economy mode)	287 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Pallet width	800 mm
Pallet height	2244 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Depth	395 mm
Width	466 mm
Height	140 mm
Weight	8400 g
Package depth	573 mm
Package width	531 mm
Package height	350 mm
Package weight	13050 g
