Epson EH-TW9100W User Manual

Maintenance
90
Maintenance
Cleaning the Parts
You should clean the projector if it becomes dirty or if the quality of projected images starts to deteriorate.
Warning
Do not use sprays that contain flammable gas to remove dirt and dust from the projector's lens, air filter,
and so on. The projector may catch fire due to the high internal temperature of the lamp.
Cleaning the air filter
Clean the air filter if dust has accumulated on the air filter or when the following message is displayed.
"The projector is overheating. Make sure nothing is blocking the air vent, and clean or replace the air
filter."
Attention
•
If dust collects on the air filter, it can cause the internal temperature of the projector to rise, and this can lead
to problems with operation and shorten the optical engine's service life. It is recommended that you clean
the air filter at least once every three months. Clean them more often than this if using the projector in a
particularly dusty environment.
•
Do not rinse the air filter in water. Do not use detergents or solvents.
•
Lightly brush the air filter to clean it. If it is brushed too strongly, dust will be ground into the air filter and
cannot be removed.
a
Press the button on the remote
control or the control panel to turn off
the power, turn off the main power
switch, and then disconnect the
power cable.
b
Remove the air filter cover.
Hook your finger into the tab on the air filter
cover, and remove it from the lens side.
c
Remove the air filter.
Grip the knob in the center of the air filter
and pull it straight out.

Epson EH-TW9100W Specifications

General

RS-232 ports	1
Matrix size	0.74 \
White light output	2400 ANSI lumens
Projection distance	- m
Projection technology	3LCD
Screen size compatibility	30 - 300 \
Projection distance (tele)	1.9 - 19.2 m
Projection distance (wide)	0.9 - 9 m
Projector native resolution	1080p (1920x1080)
Keystone correction, vertical	-30 - 30 °
Full HD	Yes
Color modes (2D)	Dynamic, Cinema
Supported 3D formats	Side by side, Top and bottom, Frame packing
Analog signal format system	-
Focus	Manual
Focal length range	23 - 47 mm
Aperture range (F-F)	2 - 3.17
Vertical lens shift range	-96.3 - 96.3 %
Horizontal lens shift range	-47.1 - 47.1 %
Lamp type	E-TORL
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
Serial interface type	RS-232
USB 2.0 ports quantity	0
Noise level	- dB
Country of origin	China
2D/3D frequency image	240/480 Hz
Noise level (economic mode)	22 dB
Placement	Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.39 W
Power consumption (typical)	340 W
Power consumption (economy mode)	287 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Pallet width	800 mm
Pallet height	2244 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Depth	395 mm
Width	466 mm
Height	140 mm
Weight	8400 g
Package depth	573 mm
Package width	531 mm
Package height	350 mm
Package weight	13050 g
